| Video/Audio Input |
| IP Video Input | 8-ch |
| Audio Input | 1-ch, RCA |
| Network |
| Incoming Bandwidth | 80Mbps |
| Outgoing Bandwidth | 64Mbps |
| Remote Users | 128 |
| Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP |
| Browser | - IE (IE10/11) for Windows
- Firefox (version 52.0 and above) for Windows
- Chrome (version 45 and above) for Windows
- Edge (version 79 and above) for Windows
|
| Video/Audio Output |
| HDMI/VGA Output | - HDMI: 4K (3840x2160) at 30, 1920x1080p at 60, 1920x1080p at 50, 1600x1200 at 60, 1280x1024 at 60, 1280x720 at 60, 1024x768 at 60
- VGA: 1920x1080p at 60, 1920x1080p at 50, 1280x1024 at 60, 1600x1200 at 60, 1280x720 at 60, 1024x768 at 60
|
| Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Output | 1-ch, RCA |
| Two-Way Audio | 1-ch, RCA (Using the audio input and output) |
| Audio Compression | G.711A, G.711U |
| Synchronous Playback | 8-ch |
| Liveview Display | 1/4/6/8/9 |
| Corridor Mode Screen | 3/4/5/7/9 |
| Snapshot |
| FTP/Schedule/Event Snapshot | 4-ch snapshot, up to D1 resolution |
| Decoding |
| Decoding Format | Ultra 265/H.265 |
| Live View/Playback | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability | 4 x 4K at 30, 6 x 5MP at 30, 8 x 4MP at 30, 9 x 4MP at 25, 10 x 3MP at 30, 16 x 1080p at 30 |
| Hard Disk |
| SATA | 1 SATA interfaces |
| Capacity | Up to 8TB for each disk (The maximum HDD capacity varies with environment temperature) |
| Smart |
| VCA Detection by Camera | Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, SMD (Smart Motion Detection) |
| VCA Search | Behavior Search, People Counting Report |
| People Counting | People Flow Counting, Crowd Density Monitoring |
| Smart Intrusion Prevention (SIP), SMD by Camera | Total 4-ch |
| General Alarm |
| General Alarm | Motion, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection |
| Alert Alarm | IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal |
| External Interface |
| Network Interface | 1 RJ-45 10M/100M self-adaptive Ethernet Interface |
| USB Interface | Front panel: 1 x USB2.0, Rear panel: 1 x USB3.0 |
| RS232 | NA |
| RS485 | NA |
| Alarm In | NA |
| Alarm Out | NA |
| PoE |
| Interface | 8 RJ-45 10M/100M self-adaptive Ethernet Interface |
| Max Power | - Max 30W for single port
- Max 75W in total
|
| Supported Standard | IEEE 802.3af/at |
| General |
| Power Supply | - 452V DC/1.8A
- Power Consumption: ≤ 10W (without HDD)
|
| Working Environment | -10°C~+ 55°C (+14°F~+131°F), Humidity ≤ 90% RH (non-condensing) |
| Dimensions (WxDxH) | 260mm x 222mm x 47mm (10.2" x 8.7" x 1.8") |
| Weight (without HDD) | ≤ 0.98Kg (2.16lb) |
| Certification |
| Certification | CE, FCC, UL, RoHS, WEEE |
| CE | EN 55032: 2015, EN 61000-3-3: 2013, EN IEC 61000-3-2: 2019, EN 55035: 2017 |
| FCC | Part15 Subpart B, ANSI C63.4 |
