| Camera |
| Sensor | 1/3", 4.0 megapixel, progressive scan, CMOS |
| Minimum Illumination | Colour: 0.003 lux (F1.6, AGC ON) 0 lux with IR on |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Shutter | Auto/Manual, shutter time: 1 ~ 1/100000s |
| Adjustment angle | - Pan: 0° ~ 360°
- Tilt: 0° ~ 90°
- Rotate: 0° ~ 360°
|
| S/N | >52dB |
| WDR | 120dB |
| Lens |
| Lens type | 2.8 ~ 12mm, AF automatic focusing and motorized zoom lens |
| Iris | Fixed |
| Field of View (H) | 86.3°~35.2° |
| Field of View (V) | 47.1°~17.0° |
| Field of View (D) | 91.9°~38.6° |
| DORI Distance |
| Lens (mm) | |
| Detect (m) | - 63 (206.7ft)
- 270.0 (885.8ft)
|
| Observe (m) | - 25.2 (82.7ft)
- 108.0 (354.3ft)
|
| Recognize (m) | - 12.6 (41.3ft)
- 54.0 (177.2ft)
|
| Identify (m) | - 6.3 (20.7ft)
- 27.0 (88.6ft)
|
| Illuminator |
| IR Range | Up to 50m (164 ft) IR range |
| Wavelength | 850nm |
| LED On/Off Control | Auto/Manual |
| Video |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Frame Rate | - Main Stream: 4MP (2688*1520), Max 25fps;4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps;
- Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps;
|
| Video Bit Rate | 128 Kbps~6 Mbps |
| U-code | Support |
| OSD | Up to 4 OSDs |
| Privacy Mask | Up to 4 areas |
| ROI | Up to 8 areas |
| Video Stream | Dual streams |
| Image |
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital noise reduction | 2D/3D DNR |
| Smart IR | Support |
| Flip | Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise |
| HLC | Support |
| BLC | Support |
| Defog | Digital Defog |
| Events |
| Basic Detection | Cross line, intrusion (based on human body detection), Motion detection, Ultra motion detection, Tampering alarm, Audio Detection |
| General Function | Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP authentication |
| Audio |
| Audio Compression | G.711A, G.711U |
| Audio Bitrate | 64 Kbps |
| Suppression | Supported |
| Sampling Rate | 8KHz |
| Storage |
| Edge Storage | Micro SD, up to 256 GB |
| Network Storage | ANR, NAS (NFS) |
| Network |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SNMP, QoS, RTMP,SSL/TLS |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API, SDK |
| User/Host | Up to 32 users. 3 user levels: administrator, operator and common user |
| Security | Password protection, strong password, HTTPS encryption, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF |
| Client | |
| Web Browser | - Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above
- Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
|
| Interface |
| Built-in Mic | Support |
| Network | 1 x RJ45 10M/100M Base-TX Ethernet |
| Certification |
| EMC | - CE-EMC (EN 55032,EN 61000-3-3,EN IEC 61000-3-2,EN 55035)
- FCC (FCC 47 CFR part15 B)
|
| Safety | - CE LVD (EN 62368-1)
- CB (IEC 62368-1)
- UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1)
|
| Environment | CE-RoHS (2011/65/EU; (EU)2015/863); WEEE (2012/19/EU) |
| Protection | IP67 (IEC 60529) |
| General |
| Power | - DC12V (plusmn;25%), PoE (IEEE 802.3af)
- Power consumption: Max 9.6W
|
| Power Interface | Ø 5.5mm coaxial power plug |
| Dimensions (L x W x H) | 206 x 73 x 73mm (8.1” x 2.9” x 2.9”) |
| Weight | 0.51kg (1.12lb) |
| Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Surge Protection | 6KV |
 |
