| Camera |
| Sensor | 1/2.7", 8.0 megapixel, progressive scan, CMOS |
| Minimum Illumination | Colour: 0.01 lux (F1.6, AGC ON) 0Lux with IR on |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Shutter | Auto/Manual, 1 ~ 1/100000s |
| Adjustment angle | - Pan: 0° ~ 360°
- Tilt: 0° ~ 90°
- Rotate: 0° ~ 360°
|
| S/N | 120dB |
| WDR | >52dB |
| Lens |
| Lens Type | 1.68mm at F2.0 |
| Iris | Fixed |
| Field of View (H) | 180° |
| Field of View (V) | 100° |
| Field of View (D) | 180° |
| DORI Distance |
| Lens (mm) | 1.68 |
| Detect (m) | 37.8 (124.0ft) |
| Observe (m) | 15.1 (49.6ft) |
| Recognize (m) | 7.6 (24.8ft) |
| Identify (m) | 3.8 (12.4ft) |
| Illuminator |
| IR Range | Up to 20m (66ft) IR range |
| Wavelength | 850nm |
| IR On/Off Control | Auto/Manual |
| Video |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 code profile | Baseline profile, Main profile, High profile |
| Frame Rate | - Main Stream: 8MP (3840*2160), Max 30fps;5MP (3072*1728), Max 30fps; 4MP (2560*1440), Max 30fps; 1080P (1920*1080), Max 30fps; 720P (1280*720) Max 30fps
- Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360, Max 30fps; 2CIF (704*288), Max 30fps; CIF (352*288), Max 30fps;
- Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF (704*288), Max 30fps; CIF (352*288), Max 30fps;
|
| Video Bit Rate | 128 Kbps~6144 kbps |
| Smart Encoding | Support |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 4 areas |
| ROI | Up to 8 areas |
| Video Stream | Triple streams |
| Image |
| Auto Scene Match (ASM) | Support(Only WDR) |
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital noise reduction | 2D/3D DNR |
| Smart IR | Support |
| Flip | Normal/ Flip Vertical/ Flip Horizontal/180° |
| Dewarping | Support |
| HLC | Support |
| BLC | Support |
| Defog | Digital Defog |
| Intelligent |
| Smart intrusion prevention | Support false alarm filtering: Line crossing detection, Intrusion detection, Enter Area detection, Leave Area detection |
| Attribute Collection | SIP with color retrieval |
| Events |
| Basic Detection | Motion detection, Ultra motion detection, Tampering alarm, Audio detection |
| General Function | Watermark, IP address filtering, Tampering alarm, Access policy, ARP protection, RTSP authentication, User authentication |
| Audio |
| Audio Compression | G.711A,G.711U |
| Audio Bitrate | 64 Kbps |
| Suppression | Supported |
| Sampling Rate | 8KHZ |
| Storage |
| Edge Storage | Micro SD, up to 256GB |
| Network Storage | ANR, NAS (NFS) |
| Network |
| Protocols | IPV4, IPV6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP,SSL, TLS, SSH |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API , SDK |
| User/Host | Up to 32 users. 2 user levels: administrator and common user |
| Security | Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2 , WSSE and digest authentication for ONVIF |
| Client | |
| Web Browser | - Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above
- Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
|
| Interface |
| Built-in Mic | Support |
| Network | 1 RJ45 10M/100M Base-TX Ethernet |
| Certification |
| EMC | - CE-EMC (EN 55032,EN 61000-3-3,EN IEC 61000-3-2, EN50130)
- FCC (FCC 47 CFR part15 B)
|
| Safety | - CE LVD (EN 62368-1)
- UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1)
|
| Environment | CE-RoHS (2011/65/EU; (EU)2015/863); WEEE (2012/19/EU) |
| Protection | IP67 (IEC 60529) |
| General |
| Power | - DC 12Vplusmn;25%, PoE (IEEE 802.3af)
- Power consumption: Max 7W
|
| Power Interface | Ø 5.5mm coaxial power plug |
| Dimensions (L x W x H) | 198x 71 x 71mm (7.8” x 2.8” x 2.8”) |
| Weight | 0.43kg (0.94lb) |
| Material | Metal |
| Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Surge Protection | 4KV |
| Reset Button | Support |
| Web Client Language | 20 Languages:- Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese
|
 |
