| Printer Method | Direct Thermal (Thermosensitive type) |
| Print Speed | 180 mm/sec |
| Printer Case Color | Black |
| Print Resolution | 8 dots/mm (203 dpi) |
| Bar Codes | - 1D: UPC-A, UPC-E, JAN/EAN8, JAN/EAN13, ITF, CODE39, CODE93, CODE128, CODABAR (NW-7) GS1-128, GS1 Omnidirectional, GS1 Truncated, GS1 Limited, GS1 Expanded
- 2D: PDF417, GS1 Stacked, GS1 Stacked Omnidirectional, GS1 Expanded Stacked, QR Code
- Composite: GS1 Composite Symbols
|
| Media Supported | Linerless Label (Sticky + Permanent), Die Cut Label, Continuous Label, Thermal Receipt |
| Paper Load | "Drop-in and print" paper loading |
| Paper Out Sensor | Standard |
| Paper Low Sensor | Standard |
| Multiple Print Widths | Prints on any paper width between 25mm - 80mm |
| Top Margin | 3mm (default), 11mm |
| Auto-Cutter | Guillotine, Partial & Full Cut |
| Sensors | - Taken, Paper Jam
- GAP, BM, PE, Cover Open
- Paper Width
- Paper Roll Position
- Cutter Home Position
- If mC-Label3 gets too hot, printing will pause until the temperature returns to normal
|
| Water & Insect Proofing | Protection equivalent to an IP22 rating |
| Logo Store Capacity | Unlimited |
| Power Supply | External: PS65AT-24A |
| Drivers | Windows 10, Windows 8.1, Windows XP 32 Bit, Vista 32/64 Bit, Windows 7 32/64 Bit, Server 2008 32/64 Bit, XP Embedded, POSReady2009, OPOS, JavaPOS, USB Vendor Class, CUPS, Mac, Mac OS X, Linux, StarPRNT SDK with support for iOS and Android |
| Software | CloudPRNT, StarwebPRNT (H/W), StarwebPRNT browser, PassPRNT, StarXpand SDK, StarPRNT SDK |
| Digitally Signed (WHQL) | Yes |
| Swappable Interfaces | N/A |
| Emulation Modes | StarPRNT |
| Power Consumption | At 24 VDC, room temperature, without USB power supply:- During power ON idling: Approx. 0.08 A (average)
- During ASCII printing: Approx. 2.1 A (average)
|
| Operating Conditions | - Temperature: 5°C to 45°
- Humidity: 10% - 90% RH (without condensation)
- 10% - 80% RH (without condensation)
|
| Storage Conditions | - Temperature: -20°C to 60°C
- Humidity: 10% - 90% RH (no condensation)
|
| Dimensions | 143 x 212 x 169mm (w x h x d) |
| Safety Standards | UL, C-UL, TuV, FCC, VCCI, EN55022, CE |
| Reliability MCBF | 36 Million Lines |
| Print Head | - Permanent Linerless Label Paper: 30 km (30 million pulses)
- Repositionable Sticky Linerless Label Paper: 75 km (75 million pulses)
|
| Auto Cutter | - Permanent Linerless Label Paper: 200k cuts
- Repositionable Sticky Linerless Label Paper: 1 million cuts
|
| Replacement Parts | - Cutter Unit
- Platen Roll Unit
- 2 in 1 (Cutter unit & Platen unit set)
|
