Samlex EVO-2212 07942 Evolution Series Inverter/Charger

Samlex, EVO-2212, 07942 Evolution Series Pure Sine Inverter/Charger, 2200 Watt, 12VDC Input, 120 VDC

Features:

• AC Inputs:
  • Two separate AC inputs - one for grid (priority #1), and one for generator (priority #2), connect simultaneously.
  • Each AC input is programmable for voltage and frequency. The user determines what the min and max thresholds are to switch from Grid or Generator to Inverter.
  • Generator start can be initiated by the "Status Relay" contact and can be programmed to activate when the grid is lost.
• Solar Input:
  • Connect a solar charge controller directly to the EVO through the Battery Charger's external DC Input, seamlessly integrating solar charging into the EVO's power system.
  • ONLINE Mode can be used to prioritize Batteries/Inverters over the grid, ideal for those wishing to operate primarily on solar power.
• Battery Charger
  • 3 or 4-stage charging with Equalization (must be manually initiated).
  • An adaptive algorithm is used during Bulk to assess the condition of the battery. Subsequent stages are then based on the condition of the battery rather than pre-set time periods for Absorption and Float. Prevents unnecessary charging, and extends the life of batteries.
  • Programmable - set battery voltage thresholds to initiate charging.
• Transfer Switch
  • Zero transfer time when switching from Inverter to Grid. When the grid comes on, the inverter synchronizes with the waveform and then transfers instantly at zero crossing.
  • < 16ms transfer when going from Grid to Inverter. When the grid is lost, the transfer relay switches to the inverter at the correct place in the waveform, the transfer takes less than 16ms.
• Surge Capacity (Power Boost)
  • The EVO has 3X surge power
  • Additionally, the EVO has large power overload allowances for long periods of time. Increased inverter capacity means you can size your inverter smaller to handle heavy surge loads, reducing costs.
• State-of-the-Art Technology
  • The EVO operates at 165 million instructions per second producing lightning-fast load and response times
  • The EVO is practically indestructible. It has "Bullet-Proof Intelligence" in the form of 9 physical points of protection monitoring being scanned up to 10,000 times per second for adverse conditions. The EVO will detect fault conditions and initiate a healthy shutdown before any product damage can be done.
  • The EVO-RC remote control (sold separately) can be used to capture detailed EVO performance data. Records all detected faults and the conditions leading up to them. Data is stored on a removable 32GB SD Card (in the remote). Use data to analyze trends for more efficient use of system resources
  • The EVO uses five temperature sensors placed throughout the unit to determine the operation of 2 speed-controlled cooling fans. Reduces unnecessary fan noise and energy consumption by only running when and where the fans are needed.

Applications:

• Boats, RVs, trucks, specialty vehicles
• Alternative energy, off-grid, cabins, remote locations, areas with unreliable utility power
• Back-up and emergency power applications

Pure sine wave inverter, adaptive battery charger, transfer relay - All in ONE unit. Samlex Evolution™ Series inverter/chargers provide reliable AC power wherever it's needed. For use with boats, RVs, cabins and specialty vehicles, as well as alternative energy, backup, and emergency power applications. Using state-of-the-art technology, the Samlex EVO™ inverter/charger operates at 165 million instructions per second with lightning fast load & response times, has 9 points of physical protection monitoring (being scanned up to 10,000 times per second) to detect fault conditions & protect itself in a vast range of adverse environments.
