Buy Qnap TVS-EC1280U-SAS-RP-16G-R2-US, NAS Enclosure, 3.4 GHz, 16GB

info@megasolutions.llc

1-855-969-9322
1-908-282-3332 (Intl.)

TVS-EC1280U-SAS-RP-16G-R2-US Includes Only:

QNAP 12-Bay SAS NAS/iSCSI/IP-SAN Unified NAS Enclosure
4 x Ethernet Cables
2 x Power Cords
48 x 3.5" HDD Flat Head Screws
48 x 2.5" HDD Flat Head Screws

The QNAP 12-Bay SAS NAS/iSCSI/IP-SAN Unified NAS Enclosure quickly takes care of your enterprise data storage needs by featuring two 10GbE SFP+ ports and 12 bays, which can house 12 Gb/s SAS and 6 Gb/s SATA 3.5" or 2.5" drives. Once drives are installed, a quad-core 3.5 GHz Intel Xeon E3-1246 v3 processor and 16GB of DDR3 non-ECC memory run iSCSI and virtualization applications as well as the QTS operating system. You can configure your drives in a RAID 0, 1, 5, 6, or 10 mode to enhance the drive's reads and writes, while preserving data in the event a drive fails. To increase throughputs, QNAP has outfitted this enclosure with two 128GB mSATA modules set up for caching data. Additionally, four Gigabit Ethernet ports are on board to serve large numbers of simultaneous connections. Powering and cooling these features are accomplished with two redundant 450W PSUs and four 60mm fans. With a well-rounded set of backup solutions integrated, critical business information can be safely protected against unexpected data loss with real-time or scheduled data backups to a remote server. For safeguarding your data, this enclosure encrypts your data with FIPS 140-2 AES 256-bit encryption. It supports SMB/CIFS, NFS, and AFP protocols for file sharing across Windows, Mac, and Linux/UNIX networks. In addition, you can meet future data needs by cascading optional QNAP RAID expansion enclosures.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

CPU

3.5 GHz Intel Xeon E3-1246 v3 quad-core

Memory

System Memory: 16 GB of DDR3 non-ECC RAM
Memory Modules Pre-Installed: 2 x 8 GB
Total Memory Slots: 4
Memory Expandable up to: 32 GB (4 x 8 GB)

Flash Memory

512 MB DOM

Internal Cache Port

Two mSATA ports on board for read caching. The standard system is shipped with 2 x 128 GB of mSATA flash

Hard Drive

12 x 3.5" SAS 12 Gbps, SAS/SATA 6 Gbps & 3 Gbps hard drives, or 2.5" SAS/SATA SSD hard drives

Hard Drive Trays

12 x hot-swappable and lockable trays

LAN Port

Built-in 2 x 10 GbE (SFP+) and 4 x GbE
40 GbE is optional

LED Indicators

10 GbE, Status, LAN, Storage expansion port status

USB

4 x USB 3.0 ports (rear)
4 x USB 2.0 ports (rear)
Supports USB printer, pen drive, USB hub, and USB UPS etc

Buttons

System: Power button and reset button

Alarm Buzzer

System warning

Form Factor

2U, Rackmount

Sound Level

Sound Level (dB) Sound pressure (LpAm) (bystander position): 49.4 dB (with 12 x HITACHI HUS724020ALA640 hard drives installed)

Power Consumption

Sleep mode: 80.41 W
In Operation: 166.58 W (with 12 x HITACHI HUS724020ALA640 hard drives installed)

Temperature

32 to 104°F / 0 to 40°C

Relative Humidity

5~95% non-condensing
Wet Bulb: 81°F / 27°C

Power Supply

Redundant Power: Input 90 to 264 VAC; 2 x 450 W

PCIe Slots

2 (right slot: 1 x PCIe Gen3 x8; left slot: 1 x PCIe Gen3 x4)

Fan

4 x 6 cm smart cooling fans

Operating System

QTS (QNAP Turbo NAS System)

Supported Browsers

Microsoft Internet Explorer 10+
Mozilla Firefox 8+
Apple Safari 4+
Google Chrome

Multilingual Support

Chinese (Traditional & Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish

File System

Internal Hard Drive: EXT4
External Hard Drive: EXT3, EXT4, NTFS, FAT32, HFS+

Networking

TCP/IP (IPv4 & IPv6: Dual Stack)
Quad Gigabit NICs with Jumbo Frame
Failover
Multi-IP Settings
Port Trunking/NIC Teaming (Modes: Balance-RR, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-TLB and Balance-ALB)
Optional Dual-port 10 GbE and 1 GbE Network Expansion Cards
Service Binding Based on Network Interfaces
Proxy Client, Proxy Server
DHCP Client, DHCP Server
Protocols: CIFS/SMB, AFP (v3.3), NFS (v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
UPnP & Bonjour Discovery
USB Wi-Fi Adapter Support

Security

IP Filter & Policy-based Automatic IP Blocking
Network Access Protection with Auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
Encrypted Access: HTTPS, FTP with SSL/ TLS (Explicit), SSH/SFTP (admin only), Encrypted Remote Replication (Rsync over SSH)
CIFS Host Access Control for Shared Folders
Antivirus Protection
FIPS 140-2 Validated AES 256-bit Volume-based Data Encryption
AES 256-bit External Drive Encryption
Importable SSL Certificate
Instant Alert via E-mail, SMS, Beep, and LCD Panel

Disk Management

QNAP Flexible volume
Thin-provisioning with space reclamation supported
Online Volume Expansion
Online Storage Pool Expansion (via QNAP RAID expansion enclosure)
Single Disk, JBOD, RAID 0, 1, 5, 6, 10
RAID Hot Spare and Global Hot Spare
Online RAID Capacity Expansion and Online RAID Level Migration
Bad Block Scan and Hard Drive S.M.A.R.T.
Bad Block Recovery
RAID Recovery
Bitmap Support

Domain Authentication Integration

Microsoft Active Directory (AD)
LDAP Server
LDAP Client
Domain Users Login via CIFS/SMB, AFP, FTP, and File Station

Web Administration

Multi-window, Multi-tasking based System Management
Movable Icons and Personalized Desktop
Smart Toolbar and Dashboard for Neat Display on System Status
Smart Fan Control
Dynamic DNS (DDNS)
SNMP (v2 & v3)
Resource Monitor
Network Recycle Bin for File Deletion via CIFS/SMB and AFP
Automatic Cleanup
File Type Filter
Comprehensive Logs (Events & Connection)
Syslog Client
Firmware Live Update
System Settings Backup and Restore
Restore to Factory Default
Mobile App Qmanager for Remote Monitoring

Product Details

CPU

3.5 GHz Intel Xeon E3-1246 v3 quad-core

Memory

System Memory: 16 GB of DDR3 non-ECC RAM
Memory Modules Pre-Installed: 2 x 8 GB
Total Memory Slots: 4
Memory Expandable up to: 32 GB (4 x 8 GB)

Flash Memory

512 MB DOM

Internal Cache Port

Two mSATA ports on board for read caching. The standard system is shipped with 2 x 128 GB of mSATA flash

Hard Drive

12 x 3.5" SAS 12 Gbps, SAS/SATA 6 Gbps & 3 Gbps hard drives, or 2.5" SAS/SATA SSD hard drives

Hard Drive Trays

12 x hot-swappable and lockable trays

LAN Port

Built-in 2 x 10 GbE (SFP+) and 4 x GbE
40 GbE is optional

LED Indicators

10 GbE, Status, LAN, Storage expansion port status

USB

4 x USB 3.0 ports (rear)
4 x USB 2.0 ports (rear)
Supports USB printer, pen drive, USB hub, and USB UPS etc

Buttons

System: Power button and reset button

Alarm Buzzer

System warning

Form Factor

2U, Rackmount

Sound Level

Sound Level (dB) Sound pressure (LpAm) (bystander position): 49.4 dB (with 12 x HITACHI HUS724020ALA640 hard drives installed)

Power Consumption

Sleep mode: 80.41 W
In Operation: 166.58 W (with 12 x HITACHI HUS724020ALA640 hard drives installed)

Temperature

32 to 104°F / 0 to 40°C

Relative Humidity

5~95% non-condensing
Wet Bulb: 81°F / 27°C

Power Supply

Redundant Power: Input 90 to 264 VAC; 2 x 450 W

PCIe Slots

2 (right slot: 1 x PCIe Gen3 x8; left slot: 1 x PCIe Gen3 x4)

Fan

4 x 6 cm smart cooling fans

Operating System

QTS (QNAP Turbo NAS System)

Supported Browsers

Microsoft Internet Explorer 10+
Mozilla Firefox 8+
Apple Safari 4+
Google Chrome

Multilingual Support

File System

Internal Hard Drive: EXT4
External Hard Drive: EXT3, EXT4, NTFS, FAT32, HFS+

Networking

TCP/IP (IPv4 & IPv6: Dual Stack)
Quad Gigabit NICs with Jumbo Frame
Failover
Multi-IP Settings
Port Trunking/NIC Teaming (Modes: Balance-RR, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-TLB and Balance-ALB)
Optional Dual-port 10 GbE and 1 GbE Network Expansion Cards
Service Binding Based on Network Interfaces
Proxy Client, Proxy Server
DHCP Client, DHCP Server
Protocols: CIFS/SMB, AFP (v3.3), NFS (v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
UPnP & Bonjour Discovery
USB Wi-Fi Adapter Support

Security

IP Filter & Policy-based Automatic IP Blocking
Network Access Protection with Auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
Encrypted Access: HTTPS, FTP with SSL/ TLS (Explicit), SSH/SFTP (admin only), Encrypted Remote Replication (Rsync over SSH)
CIFS Host Access Control for Shared Folders
Antivirus Protection
FIPS 140-2 Validated AES 256-bit Volume-based Data Encryption
AES 256-bit External Drive Encryption
Importable SSL Certificate
Instant Alert via E-mail, SMS, Beep, and LCD Panel

Disk Management

QNAP Flexible volume
Thin-provisioning with space reclamation supported
Online Volume Expansion
Online Storage Pool Expansion (via QNAP RAID expansion enclosure)
Single Disk, JBOD, RAID 0, 1, 5, 6, 10
RAID Hot Spare and Global Hot Spare
Online RAID Capacity Expansion and Online RAID Level Migration
Bad Block Scan and Hard Drive S.M.A.R.T.
Bad Block Recovery
RAID Recovery
Bitmap Support

Domain Authentication Integration

Microsoft Active Directory (AD)
LDAP Server
LDAP Client
Domain Users Login via CIFS/SMB, AFP, FTP, and File Station

Web Administration

Multi-window, Multi-tasking based System Management
Movable Icons and Personalized Desktop
Smart Toolbar and Dashboard for Neat Display on System Status
Smart Fan Control
Dynamic DNS (DDNS)
SNMP (v2 & v3)
Resource Monitor
Network Recycle Bin for File Deletion via CIFS/SMB and AFP
Automatic Cleanup
File Type Filter
Comprehensive Logs (Events & Connection)
Syslog Client
Firmware Live Update
System Settings Backup and Restore
Restore to Factory Default
Mobile App Qmanager for Remote Monitoring

Note

Note: Please read description carefully. Do not base your order on the picture presented.
