| Cellular Module | Quectel EG25-G |
| Regions | - Australia
- Canada
- European Union
- Japan
- Korea
- United Kingdom
- United States
|
| Cellular Module Performance**** | - 3GPP Release 11
- 4G-LTE FDD/TDD Category 4
- 150 Mbps peak downlink
- 50 Mbps peak uplink with 3G/2G fallback
|
| Frequency Band (MHz ) | - 4G LTE FDD (Europe):
B1(2100), B3(1800), B7(2600), B8(900), B20(800), B28(700) - 3G (Europe Fallback): B1(2100), B3(1800), B8(900)
- 2G (Europe Fallback): B2(1900), B3(1800), B8(900)
- 4G LTE FDD (AT&T): B2(1900), B4(AWS1700), B12(700)
- 4G LTE FDD (Verizon): B4(AWS1700), B13(700)
- 4G LTE FDD: B5(850), B18(800), B19(800), B25(1900), B26(850)
- 4G LTE TDD: B38(2600), B39(1900), B40(2300), B41(2500)
|
| Diversity/MIMO | Rx Diversity and MIMO DL 2x2 |
| SMS | Mobile Originate, Mobile Terminated, Point-to-Point |
| Processor & Memory | - ARM9 processor with 32-Bit ARM & 16-Bit Thumb instruction sets
- 400 MHz
- 16K Data Cache
- 16K Instruction Cache
- 128X16 MB DDR RAM
- 256 MB Flash Memory
|
| Wi-Fi / Bluetooth (-247 models) | Wi-Fi: 802.11abng (2.4 & 5 GHz) / Bluetooth: Classic 4.1 and BLE |
| GNSS (-246 and -247 models) | - GNSS for LoRa Packet Time Stamping
- Concurrent GNSS connections: (3)
- GNSS Systems Supported: (default: concurrent GPS/QZSS/SBAS and GLONASS)
|
| LEDs | - PWR (Power)
- STATUS (Power Status)
- LS (Link Status)
- CD (Carrier Detect)
- SIGNAL (Signal Strength)
|
| Gateway Accessory Card | MTAC-003U00; MTAC-LORA-H-915 |
| LoRa Frequency Band | 915 MHz |
| LoRa Channel Plan | US915 |
| Channel Capacity | 8-channels (half-duplex) |
| LoRa Power Output | 27 dBm maximum output power before antenna |
| LoRaWAN Standard | LoRaWAN 1.0.3 specifications |
| Standard Connectors (all models) | - Power: 9 - 32 VDC 2.5 mm miniature barrel jack (screw-on)
- E-NET: RJ-45 Ethernet jack (10/100)
- USB DEVICE: USB 2.0 Micro B
- USB HOST: (1) USB 2.0 Type A
- AP1, AP2: Slots for MTAC Accessory Cards
- SIM (under nameplate): mini SIM (2FF) 1.8 & 3V
- Micro SD Card (under nameplate): 32 GB (HSMCI) max (industrial temperature range recommended)
- Debug Port (under nameplate): micro USB or 3-pin connector
- RESET: Push-button reset switch
|
| Antenna Connectors (-246 models) | Antenna: (3) SMA (cellular, auxiliary, GPS) |
| Antenna Connectors (-247 models) | Antenna: (4) SMA (cellular, auxiliary, GPS, Wi-Fi) |
| Additional Antenna Connectors (LoRaWAN models) | Antenna: (1) SMA (RF-LoRaWAN) |
| Dimensions | 6.35" x 4.23" x 1.69" (161.3 mm x 107.4 mm x 42.8 mm) |
| Weight | 1.0 lbs (0.45 kg) |
| Chassis Type | Anodized aluminum (blue) |
| Mounting Options | Desktop / Wall mount / DIN rail mount (using DIN-FLANGE Accessory) |
| Input Voltage | - 9-32 VDC at 1.7A
- provided to 100 - 240 VAC 50/60 Hz external adaptor or fused DC Power Cable
|
| Power Draw @ 9 VDC***** | Sleep Mode: N/A / Idle: 700 mA / Max Power: 1250 mA (average) |
| Operating Temperature | -30° to +70° C*** |
| Storage Temperature | -30° to +70° C |
| Relative Humidity | 20 to 90% non-condensing |
| EMC / Radio Compliance | - CE
- FCC Part 15 Class B
- IC Class B
- KCC (Korea)
- Radio Law (Japan)
- RCM
- UKCA
|
| Safety Compliance | UL/cUL/IEC 60950-1 |
| Network Compliance | PTCRB |
| Network Operator | AT&T, Verizon (Carrier approved MTSMC-L4G1-U) |
- * See hardware guides for additional information.
- ** Some devices are shipped with MTAC gateway accessory card installed at factory. See ordering part number for details.
- *** UL Listed @ 40° C, limited by AC power supply. UL Recognized @ 65° C for Conduit LTE devices when used with the fused DC power cable, part number FPC-532-DC.
- **** Actual device performance may be affected by a variety of attributes such as cell tower distance, data loads, packet sizes, etc.
- ***** See Hardware Guide for additional power meaurements
- ****** All future end-user (OEM) devices will and must go through FirstNet certification prior to being included in the FirstNet device ecosystem
- ******* Maximum EIRP is 14 dBm for most of the band, except 27 dBm at 869.4 - 869.65
- ******** Optional power must be UL Listed ITE power supply marked LPS or Class 2 rated with rating between 9 -32 Vdc minimum of 1A .
|
