Lumens VC-A71SNB 4K NDI PTZ Camera with NDI HX3 and 12G-SDI Black

Color: Black
  • Brand Lumens
  • Part # VC-A71SNB
  • Condition
    Brand New
    Availability
    Typically In Stock
    Quantity
    Share:
    Ask a question

    Options and Related Products

    Color:
    Color: Black

    Features:

    • 2160p 60, 30x optical zoom, 1/1.8" Sensor
    • 12G-SDI, HDMI, Ethernet, USB3.0 output
    • Support NDI HX3 / NDI HX2 / RTSP / RTMP / RTMPS / MPEG- TS / SRT
    • Support FreeD protocol for live VR/AR production
    • Support BT.2020 color space

    ndi hx3 technology

    NDI HX3 Technology

    VC-A71SN supports the latest version of the NDI protocol, NDIHX3. It delivers very high-quality video with ultra-low latency and connects directly to NDInetworks.

    video output

    12G-SDI

    Lumens VC-A71SN is equipped with an 12G-SDI video output. This port delivers UltraHD at up-to 60 frames a second, meaning it can capture fast motion and deliver smooth video output.

    BT.2020/Rec.709

    Lumens VC-A71SN supports the BT.2020 color gamut for wide and precise color reproduction. With BT.2020, VC-A71SN will be easy to match other cameras and deliver video output optimized for new generation UltraHD monitors.

    Live VR/AR Video Production

    VC-A71SN supports the FreeD protocol.This enables users to work with Virtual Reality and Augmented Reality sets without the need for additional sensors.

    Smooth PTZ Movement

    With high-precision motor control and Lumens’ innovative mechanical transmission mechanism, VC-A71SN achieves smooth, high-speed movement without any judder. The speed of movement is fully customizable.

    See more product information See less

    We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

    Technical Details

    Optional Accessories
    Reviews
    Sensor1/1.8" 9.17 MP CMOS
    Video Format2160p: 59.94 / 50 / 29.97 / 25, 1080p: 59.94 / 50 / 29.97 / 25, 1080i: 59.94 / 50, 720p: 59.94 / 50
    Video Output (HD) Interface12G-SDI / HDMI 2.0 / Ethernet / USB 3.0
    Optical Zoom30x
    Digital Zoom12x
    Horizontal Viewing Angle63° (Wide) to 3.7° (Tele)
    Vertical Viewing Angle35.4° (Wide) to 2.1° (Tele)
    Diagonal Viewing Angle72.3° (Wide) to 4.2° (Tele)
    ApertureF1.6 ~ F4.8
    Focal Length6.5mm ~ 202mm
    Shutter Speed1/1 ~ 1/10,000 sec
    Minimum Object Distance1.5m (Wide / Tele)
    Video S/N Ratio≥ 50dB
    Minimum Illumination0.05 lux (F1.6, 50IRE, 30fps)
    Focus SystemAuto / Manual
    Gain ControlAuto / Manual
    White BalanceAuto / Manual / Smart AE
    Exposure ControlAuto / Manual / Smart AE
    IQ SyncYes
    WDRYes
    3D NRYes
    Image FlipYes
    Color SpaceStandard / BT.2020 / REC.709
    AR/VR SystemsFreeD
    NDI GenlockYes
    Tally LightYes
    Pan Speed300°/sec
    Panning Angle+170° ~ -170°
    Tilt Speed300°/sec
    Tilting Angle+90° ~ -30°
    Preset Positions256
    HDMI / 12G-SDI2160p 59.94
    IP StreamND1: HEVC(H.265) 4K 59.94fps, H.264 640x360 29.97fps orRTSP: HEVC(H.265) 4K 59.94fps, H.264 1080p 59.94fps, H.264 640x360 29.97fps
    IP CompressionH.264 / HEVC(H.265)
    USB OutputH.264 4K 30fpsMJPEG 1080p 30fps
    USB CompressionH.264 / MJPEG
    IP ProtocolNDI HX3 / NDI HX2 / RTSP / RTMP / RTMPS / MPEG-TS / SRT
    PoEPoE++ (IEEE802.3bt)
    InputLine In/MIC In, Phone Jack 3.5mm x1
    OutputEthernet / 12G-SDI / HDMI 2.0 / USB 3.0
    Compression FormatAAC / G.711 / PCM
    InterfaceRS-232 / RS-422 / Ethernet / USB 3.0 / Remote
    ProtocolVISCA / VISCAIP / ONVIF / PELCO D / NDI / UVC
    DC IN12V +/- 20%
    Power ConsumptionPoE: 27.5 WDC in: 27 W
    Weight6.6 lbs (3 kg)
    Dimensions (WxHxD)9.1" x 7.4" x 7.4" (232 x 188 x 189 mm)
    Notes

    * Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

    Product Details
    Sensor1/1.8" 9.17 MP CMOS
    Video Format2160p: 59.94 / 50 / 29.97 / 25, 1080p: 59.94 / 50 / 29.97 / 25, 1080i: 59.94 / 50, 720p: 59.94 / 50
    Video Output (HD) Interface12G-SDI / HDMI 2.0 / Ethernet / USB 3.0
    Optical Zoom30x
    Digital Zoom12x
    Horizontal Viewing Angle63° (Wide) to 3.7° (Tele)
    Vertical Viewing Angle35.4° (Wide) to 2.1° (Tele)
    Diagonal Viewing Angle72.3° (Wide) to 4.2° (Tele)
    ApertureF1.6 ~ F4.8
    Focal Length6.5mm ~ 202mm
    Shutter Speed1/1 ~ 1/10,000 sec
    Minimum Object Distance1.5m (Wide / Tele)
    Video S/N Ratio≥ 50dB
    Minimum Illumination0.05 lux (F1.6, 50IRE, 30fps)
    Focus SystemAuto / Manual
    Gain ControlAuto / Manual
    White BalanceAuto / Manual / Smart AE
    Exposure ControlAuto / Manual / Smart AE
    IQ SyncYes
    WDRYes
    3D NRYes
    Image FlipYes
    Color SpaceStandard / BT.2020 / REC.709
    AR/VR SystemsFreeD
    NDI GenlockYes
    Tally LightYes
    Pan Speed300°/sec
    Panning Angle+170° ~ -170°
    Tilt Speed300°/sec
    Tilting Angle+90° ~ -30°
    Preset Positions256
    HDMI / 12G-SDI2160p 59.94
    IP StreamND1: HEVC(H.265) 4K 59.94fps, H.264 640x360 29.97fps orRTSP: HEVC(H.265) 4K 59.94fps, H.264 1080p 59.94fps, H.264 640x360 29.97fps
    IP CompressionH.264 / HEVC(H.265)
    USB OutputH.264 4K 30fpsMJPEG 1080p 30fps
    USB CompressionH.264 / MJPEG
    IP ProtocolNDI HX3 / NDI HX2 / RTSP / RTMP / RTMPS / MPEG-TS / SRT
    PoEPoE++ (IEEE802.3bt)
    InputLine In/MIC In, Phone Jack 3.5mm x1
    OutputEthernet / 12G-SDI / HDMI 2.0 / USB 3.0
    Compression FormatAAC / G.711 / PCM
    InterfaceRS-232 / RS-422 / Ethernet / USB 3.0 / Remote
    ProtocolVISCA / VISCAIP / ONVIF / PELCO D / NDI / UVC
    DC IN12V +/- 20%
    Power ConsumptionPoE: 27.5 WDC in: 27 W
    Weight6.6 lbs (3 kg)
    Dimensions (WxHxD)9.1" x 7.4" x 7.4" (232 x 188 x 189 mm)
