Buy Lilliput 664/W, FPV Monitor for DJI Drones, 7"

info@megasolutions.llc

1-855-969-9322
1-908-282-3332 (Intl.)

664/W Includes Only:

Monitor
Shoe Mount
Battery Plate
Battery plate bracket
Flexible folding sun shade
5.8GHz wireless AV receiver
Composite cable
12V DC adapter
Manual

Features:

Multiple power support, makes outdoor photography more convenient and practical.
No "blue screen" problem when the signal gets weak, from 100 to 2000 meters wireless distance.
Sunlight readable with ultra brightness and definition screen.

Enjoy a drone's eye view while pilot with this 7" FPV Monitor for DJI Drones from Lilliput. Utilizing a 5.8 GHz antenna, this monitor can receive a video signal from up to 1.2 miles away. The drone's video footage is displayed on the 7" IPS screen that has been designed to be ultra-bright and readable when out in the sun. The monitor also features multiple AV inputs to allow to hook up other equipment for playback.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

LCD Display

LCD Size

7.0" / 17.8 cm IPS

Display Resolution

1280 x 800

Active Area

5.9 x 3.7" / 15.0 x 9.4 cm

Dot Pitch

0.117 (H) x 0.117 (V) mm

Aspect Ratio

16:10

Brightness

400 cd/m²

Light Source

LED

Contrast Ratio

800:1

Surface Treatment

Viewing Angle

89deg

Video

Input Signal

Analog RGB

Inputs

1 x HDMI
1 x Composite
5.8 GHz Wireless AV
1 x Shutter Port

Input Connectors

1 x HDMI
1 x Composite

Transmission Range

Up to 1.2 Miles

General

Control

Power, Shutter Shortcut Button, F1-F3 User-Definable Buttons, Enter Button, Left/Right Selection Key, Menu, and Circularly Switch

Speaker

Built-In, 1 W

Language

English, Chinese

Power Requirements

12 VDC, 1500 mA

Power Consumption

andle; 12 W

Temperature

Operating: -4 to 140deg F /-20 to 60deg C
Storage: -22 to 158deg F / -30 to 70deg C
High Altitude: +140deg F / 60deg C, 80% RH Max

Dimensions (L x W x D)

7.2 x 5.1 x 0.9" / 18.5 x 13.1 x 2.3 cm

Product Details

LCD Display

LCD Size

7.0" / 17.8 cm IPS

Display Resolution

1280 x 800

Active Area

5.9 x 3.7" / 15.0 x 9.4 cm

Dot Pitch

0.117 (H) x 0.117 (V) mm

Aspect Ratio

16:10

Brightness

400 cd/m²

Light Source

LED

Contrast Ratio

800:1

Surface Treatment

Viewing Angle

89deg

Video

Input Signal

Analog RGB

Inputs

1 x HDMI
1 x Composite
5.8 GHz Wireless AV
1 x Shutter Port

Input Connectors

1 x HDMI
1 x Composite

Transmission Range

Up to 1.2 Miles

General

Control

Power, Shutter Shortcut Button, F1-F3 User-Definable Buttons, Enter Button, Left/Right Selection Key, Menu, and Circularly Switch

Speaker

Built-In, 1 W

Language

English, Chinese

Power Requirements

12 VDC, 1500 mA

Power Consumption

andle; 12 W

Temperature

Operating: -4 to 140deg F /-20 to 60deg C
Storage: -22 to 158deg F / -30 to 70deg C
High Altitude: +140deg F / 60deg C, 80% RH Max

Dimensions (L x W x D)

7.2 x 5.1 x 0.9" / 18.5 x 13.1 x 2.3 cm

Note

Note: Please read description carefully. Do not base your order on the picture presented.
