| Regulatory Conformance | - Laser Safety: IEC60825/CDRH Class II
- LED Safety: IEC62471:2006
|
| Scan Range (20 mil Code39) |
| Imager | 3.4" to 104.1" (88 mm to 2848 mm) |
| Symbologies |
| Laser/CCD (1D) | EAN-13, EAN-8, UPC-A, UPC-E, Code 39, ITF14, Code 128, Interleaved 2 of 5, Codabar, GS1-128, Code 93, Code 35, Bookland EAN-13, EAN-13/8 incl. add on, UPC-A/E incl. add on, GS1 Omni, GS1 Limited, GS1 Expanded |
| Imager (1D) | Codabar, Code 11, Code 32, Code 39, Code 93, Code 128, EAN-8, EAN-13, GS1 Composite, Interleaved 2 of 5, Matrix 2 of 5, MSI, Plessey, PosiCode, GS1 Omni, GS1 Limited, GS1 Expanded, Straight 2 of 5 Industrial, Straight 2 of 5 IATA, TCL39, Telepen, Tri-Optic, UPC-A, UPC-E0, UPC-E1 |
| Imager (2D) | Aztec Code, Aztec Runes, Codablock F, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code, Han Xin Code |
| Postal Codes | POSTNET, Planet Code, British Post, Canadian Post, Netherlands (KIX) Post, Australian Post, Japanese Post, Chinese Post, Korean Post |
| OCR Options | OCR-A, OCR-B, OCR US Currency, OCR MICR E13B, OCR Semi Font |
| When Discharging | - BLINKING RED: Low Battery
- BLINKING ORANGE: Discharging
- BLINKING GREEN: Fully Charged
|
| Physical Characteristics |
| Size | 1.69" x 3.7" x 0.94" (43 mm x 94 mm x 24 mm) |
| Weight | 3.0 oz (85 g) |
| Electrical Characteristics |
| Battery | Lithium-Ion (3.7V DC, 1100 mAh) hardpack |
| Charging | USB, Charging Cradle |
| Interfaces |
| Bluetooth® Low Energy 5.0 | HID (Android/iOS/Windows), SPP (Optional Secure Mode) |
| USB | Flash Memory (Windows), USB HID, USB Serial (Android with OTG cable / Windows) |
| User Environment |
| Ingress Protection Rating | IP65 |
| Drop Spec | 5 feet (1.5m) |
| Operating | -4°F to 122°F (-20°C to 50°C) |
| Storage | -4°F to 140°F (-20°C to 60°C) |
| Humidity | 5% to 95% (non-condensing) |
| Functionality |
| Memory Flash | - 8MB User Data
- Can store more than 400,000 barcodes (EAN-13)
|
| Wedging and Synchronization | - Store to a file or transfer to an application
- Keyboard wedge function
- Add-on prefixes and suffixes
- Barcode option selection
|
| Application Generation | - SDK for PC and smartphone application
- Application generation tool
- Database Lookup and Inventory Management features
|
| OS Support | Android, iOS, Mac OS X, Windows |
| NFC (Optional) | ISO/IEC 14443 A/B, ISO/IEC 15693, FeliCa, MIFARE (1K/4K/Ultralight/UltralightC/DESFire) |
| Wi-Fi (Optional) | - Compliance: 2.4GHz IEEE 802.11b/g/n
- Support: 802.11g/n OFDM with BPSK, QPSK, 16-QAM, 64-QAM and 802.11b with BPSK, QPSK, CCK
|
| Special Features | - NFC Pairing
- Social Distance Solution
|
