EVC4032000 Includes Only:
- 40A Charging Station
- Connector & holster
- 25ft charging cable
Features:
- SAE J1772, AC Level 2, 40A, 9.6 kW
- 2.4Ghz Wi-Fi
- 4G LTE (40A iEVSE Plus Only)
- RFID (40A iEVSE Plus Only)
- EvoCharge network or third-party network
- Universal J1772 plug
- NEMA 4 rated for indoor and outdoor use
- UL Listed and Energy Star Rated
- Local load management between chargers
- True Open Charge Point Protocol (OCPP) charging
- 240V hardwired power connection
Provide flexible and easy to use charging stations for workplace, business, or public charging. Easily manage your chargers with the EvoCharge network or another third-party. All network connected chargers arrive preconfigured for quick and simple one-touch on site commissioning.
Smart Charging
Connecting your charging station(s) via your local Wi-Fi allows you to link to third party network providers and local utility companies. Third party networks provide a multitude of features, including controlling access, setting up payment options, and tracking performance. Some networks will also help you connect to your local utility company so you can charge at off-peak times to save money.
Non-proprietary Networks
An Open Charge Point Protocol (OCPP) charging station doesn't require using a specific network to work and it can be networked through any provider in your area. This means you can still charge without being connected to a third party network, or change to a provider. EvoCharge's iEVSE and iEVSE Plus charging stations are OCPP 1.6 certified, allowing you to connect to any open network, including three preferred network partners: EV Connect, Greenlots and Chargie. The best part is we'll preconfigure your charging station to work with one of those three providers before shipping and you work with us to set up your account, billing, and more.
A charging network allows the charging station owner to monitor, control usage, bill users, and more. These networks also provide connections to local electric utility companies. Some utility companies will provide cheaper charging during off-peak hours.
Load Balancing
Local load management (LLM) allows you to use your building's existing electrical panel power capacity to charge multiple electric vehicles via charging stations by allowing the charging stations to talk to each other, doling out a steady electrical current to each. Say your electrical panel provides 80 amps, but you have four chargers that each need 40 amps at full charging capacity. If each charging station worked at full capacity at the same time, they would demand more electricity than the panel can provide, causing issues and overwhelming the electrical panel. But when the chargers are able to communicate with each other, electricity can be spread out amongst all four charging stations. There are two ways in which load-sharing electrical chargers will provide a steady stream of electricity to the stations: equally distributed or first in, first charged. Learn more here.
If your parking area doesn't have access to WiFi, you can save money by purchasing one iEVSE Plus station to connect via 4G LTE, and the rest of your units can be the iEVSE. The Plus station will share the network connection with the other charging stations, allowing you to only pay one wireless bill.
Cable Management
EvoCharge's industry-leading cable management solutions are the best way to keep your charging areas safe, organized and clean while protecting the charging cables from wear. By automatically retracting the cable onto the reel when not in use, the EvoReel keeps cords off the floor and at arm's reach, improving cleanliness, safety, and efficiency. The Retractor keeps your charging cable supported overhead and out of the way. With simple installation options, the EV Cable Retractor uses a spring-loaded tether to suspend the cord.
Certifications
EvoCharge charging stations are NEMA 4-rated. The National Electrical Manufacturer Association (NEMA) is a standard rating that defines the type of environments in which electrical enclosures can be used. NEMA 4 rating provides protection of the equipment inside the enclosure against falling dirt and dust. It also provides a degree of protection from the harmful effects due to water, rain, sleet, snow, splashing water and hose directed water. The charging station will also withstand the external formation of ice on the enclosure.
