| Enclosure Color | Black |
| Touch Technology & Capacity | PCAP (TouchPro® Projected Capacitive) - 10 Touch |
| Touch Thru | Supports up to 6mm / 0.24" glass or 3mm / 0.12" plastic with up to 2 touches |
| Processor | Standard Model: Qualcomm Snapdragon SDA660 |
| Memory (RAM) | 4GB |
| Storage | Standard Model: 64GB |
| OS | Android 10 with Google Play Services (AOSP capable) |
| Diagonal Size | 21.5'' diagonal, Active matrix TFT LCD (LED) |
| Aspect Ratio | 16:9 |
| Active Area | 18.74" x 10.54" / 476 mm x 268 mm |
| Resolution | 1920 x 1080 at 60Hz |
| Number of Colors | 8-bit (16.7 million) |
| Brightness (typical) | - Standard Model:
- LCD Panel: 250 nits
- TouchPro PCAP: 215 nits
|
| Response Time-total (typical) | Standard Model: 14 msec |
| Contrast Ratio | 1000:1 |
| Viewing Angle | - Standard Model:
- Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total
|
| Peripheral Mounting | - 4x micro-USB 2.0 Elo Edge Connect ports
- Support for 1.2A on one port and 500mA for the remaining three ports
|
| I/O Ports | - 1x USB 3.0 support (900mA)
- Type C USB output
- Micro SD slot
- GPIO
- Ethernet 1x LAN (Gigabit)
- DC in
|
| Webcam | Standard Model: 8MP, Max Resolution: 1920x1080 30fps, Auto Focus, Focus Range: >10cm |
| Wireless | 802.11a/b/g/n/ac + Bluetooth 5.0 |
| Audio Ports | Standard Model: 2x built-in Digital Microphones |
| Speakers | Standard Model: 2x 0.8W |
| Power Supply | - AC input voltage: 100-240 VAC
- Input frequency: 50-60 Hz
- power adapter (included in accessory box)
|
| Power Consumption (Typical) | - Standard Model:
- On: 19.8W
- Off: 0.4W
- Sleep: 4.4W
|
| Power Over Ethernet (PoE) | - Supported via Elo PoE Device PN: E413396
- Reference the I-Series 4.0 user guide for details.
|
| Dimensions | 20.66" x 12.79" x 1.17" / 524.8 mm x 324.8 mm x 29.7 mm |
| Weight (Unpackaged) | Standard Model: 8.4 lbs / 3.8 kg |
| Operating Temperature | 0°C to 40°C / 32°F to 104°F |
| Storage Temperature | -20°C to 50°C / -4°F to 122°F |
| Humidity | - Operating: 20% to 80%
- Storage: 5% to 95%
|
| Regulatory approvals and declarations | - UL/cUL (US)
- FCC (US)
- IC (Canada)
- CE (Europe)
- CB (International)
- VCCI, MIC (Japan)
- RCM (Australia)
|
| Supported Countries | Canada, USA, Australia, Japan, New Zealand, Austria, Belgium, Czech Republic, Denmark, France, Germany, United Kingdom, Hungary, Italy, Netherlands, Poland, Portugal, Romania, Spain, Sweden, Switzerland, Turkey, Brazil |
| Real-Time Clock | lithium coin cell battery |
| MTBF | 50,000 hours demonstrated |
