Buy ELO Touch E265991, 22" Touchscreen Monitor Full HD White Anti-Glare

info@megasolutions.llc

1-855-969-9322
1-908-282-3332 (Intl.)

Options and Related Products

Diagonal Size:: Diagonal Size: 22"
Color/Surface Treatment:: Color/Surface Treatment: White, Anti-Glare

E265991 Includes Only:

2270L Touchmonitor
Quick Install Guide
HDMI cable
Touch USB cable
NA Power cable
EU Power cable
EEI Label (EU)
2x EEI Label (UK)
2x Replace foot cover
5x Cable tie

Features:

Durable, energy efficient touchscreen.
- Scratch-resistant glass surface.
- IK07 impact resistant.
- ES8.0 certified for greater energy efficiency.
Increase viewing comfort with low blue light and flicker free features.
Navigate the OSD directly on the touchscreen.
- We have made it easier to manage your On-Screen Display (OSD) controls - Now you can use the touchscreen or the controls you are used to on the rear side of the monitor.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Enclosure Color

White

Touch Technology & Capacity

PCAP (TouchPro® Projected Capacitive) - 10 Touch

Diagonal Size

21.5'' diagonal, Active matrix TFT LCD (LED)

Aspect Ratio

16:9

Active Area

18.74" x 10.54" / 476.06 mm x 267.79 mm

Resolution

1920 x 1080 at 50, 60Hz

Other Supported Resolutions

640 x 480 60Hz
640 x 400 70Hz
720 x 400 70Hz
800 x 500 60Hz
800 x 600 56Hz, 60Hz
1024 x 768 60Hz
1280 x 720 at 58Hz, 60Hz
1280 x 800 60Hz
1280 x 1024 60Hz
1366 x 768 60Hz, 60Hz RB
1440 x 900 60Hz, 60Hz RB
1680 x 1050 60Hz, 60Hz RB

Viewing Angle

Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total

Number of Colors

16.7 million

Brightness (typical)

LCD Panel: 250 nits
TouchPro PCAP: 225 nits

Response Time-total (typical)

14 msec

Contrast Ratio

1000:1

Touch Interface

USB

Surface Treatment

Anti-glare

I/O Ports

AC Input (IEC60320 C6)
Audio in/out
VGA
HDMI
DisplayPort
USB 2.0 Type B
2x USB 2.0 Type A

Speakers

Two x 2W internal speakers

Video

VGA (Female DB-15 connector)
HDMI (receptable type A)
DisplayPort

Input Video Frequency

Horizontal: 30 – 82KHz
Vertical: 50 - 75Hz

Power

AC power input connector (IEC 60320 C6)
AC input voltage range: 100-240VAC, 50/60Hz

Power Consumption (Typical)

Only display and touch function available:
ON (Default - 80% Brightness): 12.2 W
ON (Typical - 100% Brightness): 13.8 W
SLEEP: 0.5 W
OFF: 0.16 W

Monitor Dimensions (without Stand)

19.87" x 11.91" x 1.63" / 504.7 mm x 302.4 mm x 41.3 mm

Weight (Unpackaged)

9.04 lbs / 4.1 kg

Operating Temperature

0°C to 40°C / 32°F to 104°F

Storage Temperature

-20°C to 60°C / -4°F to 140°F

Humidity

Operating: 20% to 80%; Storage: 10% to 95% (38.7°C max wet bulb temperature)

MTBF

50,000 hours demonstrated

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Enclosure Color

White

Touch Technology & Capacity

PCAP (TouchPro® Projected Capacitive) - 10 Touch

Diagonal Size

21.5'' diagonal, Active matrix TFT LCD (LED)

Aspect Ratio

16:9

Active Area

18.74" x 10.54" / 476.06 mm x 267.79 mm

Resolution

1920 x 1080 at 50, 60Hz

Other Supported Resolutions

640 x 480 60Hz
640 x 400 70Hz
720 x 400 70Hz
800 x 500 60Hz
800 x 600 56Hz, 60Hz
1024 x 768 60Hz
1280 x 720 at 58Hz, 60Hz
1280 x 800 60Hz
1280 x 1024 60Hz
1366 x 768 60Hz, 60Hz RB
1440 x 900 60Hz, 60Hz RB
1680 x 1050 60Hz, 60Hz RB

Viewing Angle

Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total

Number of Colors

16.7 million

Brightness (typical)

LCD Panel: 250 nits
TouchPro PCAP: 225 nits

Response Time-total (typical)

14 msec

Contrast Ratio

1000:1

Touch Interface

USB

Surface Treatment

Anti-glare

I/O Ports

AC Input (IEC60320 C6)
Audio in/out
VGA
HDMI
DisplayPort
USB 2.0 Type B
2x USB 2.0 Type A

Speakers

Two x 2W internal speakers

Video

VGA (Female DB-15 connector)
HDMI (receptable type A)
DisplayPort

Input Video Frequency

Horizontal: 30 – 82KHz
Vertical: 50 - 75Hz

Power

AC power input connector (IEC 60320 C6)
AC input voltage range: 100-240VAC, 50/60Hz

Power Consumption (Typical)

Only display and touch function available:
ON (Default - 80% Brightness): 12.2 W
ON (Typical - 100% Brightness): 13.8 W
SLEEP: 0.5 W
OFF: 0.16 W

Monitor Dimensions (without Stand)

19.87" x 11.91" x 1.63" / 504.7 mm x 302.4 mm x 41.3 mm

Weight (Unpackaged)

9.04 lbs / 4.1 kg

Operating Temperature

0°C to 40°C / 32°F to 104°F

Storage Temperature

-20°C to 60°C / -4°F to 140°F

Humidity

Operating: 20% to 80%; Storage: 10% to 95% (38.7°C max wet bulb temperature)

MTBF

50,000 hours demonstrated

Note

Note: Please read description carefully. Do not base your order on the picture presented.
