Crosby Straightpoint, WLP55T, Wirelink Plus Cabled Tension Load Cell, 1000 KG
WLP1T Includes Only:
- Proof test certificate
- Operator Manual
- Carry/Storage Case
- RFID Tagged
- 10M Cable
Features:
- Constructed of lightweight aluminium
- Capacities ranging from 1 to 300 tonnes
- High accuracy
- Multiple output options to include mV/V, analogue out, ASCII, MODBUS RTU and CAN-BUS
- IP68 environmental protection
- Options for subsea
Applications:
- Testing
- Overhead Weighing
- Loadcell Rental
- Bollard Pulling
- Tug Testing
- Cable Tensioning
- Heavy Lift
Wirelink plus is designed to be rigged with Crosby standard shackles - manufactured from aerospace grade aluminium and utilising an advanced internal design structure this range of non-indicating Load cells are extremely lightweight, easy to handle and are used worldwide in an array of industries for lifting, pulling, proof and structural load testing.Decades of development into this product include many stand out features such as unique strain gauging method that helps compensate for wire rope torque when the Wirelink is loaded.
The extremely versatile platform can be used with digital displays including the Straightpoint handheld plus, PLCs, Data Acquisition systems (DAQ) etc. and configured with a vast array of output formats to include mV/V, RS-422, RS-485, utilizing the ASCII, MODBUS RTU and CAN-BUS protocols.
The Wirelink plus is supplied with a 10 metre cable as standard however usable cable length varies greatly with lengths to 1500 metres depending on the output format.
For more information, please see
Product Manual
