Code B-FR22LITE-RDR-US FR22 Fixed Lite RFID Reader

Version: Lite RFID Reader
  • Brand Code
  • Part # B-FR22LITE-RDR-US
  • Model # FR22
  • Condition
    Brand New
    Availability
    Typically In Stock
    Quantity
    Share:
    Ask a question

    Options and Related Products

    Version:
    Version: Lite RFID Reader

    Features:

    • Fast and reliable edge computing with support for custom-embedded applications
    • Features an advanced technology UHF RFID engine
    • Create embedded web apps with an intuitive user interface
    • Eliminates the need for an external PC/tablet
    • Connects to external devices, sensors, triggers, lights and buzzers
    • A lower-cost alternative to the FR22 reader for applications requiring fewer connectivity

    Ensure better data management with a smarter platform: the Brady FR22 Lite RFID Reader. Count on high track and trace performance - even in challenging environments.

    See more product information See less

    We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

    Technical Details

    Reviews
    Dimensions0.69 in H x 8 in W x 3.09 in D
    Reading SpeedUp to 1000 tags per second
    Weight0.353 lb
    ColorSilver, Blue
    ApplicationAsset Tracking, Inventory and Inspection Labeling, RFID labeling, Temperature Indicating Labeling
    Shipped With BatteryNo
    Central Processing Unit (CPU)Quad-core A7 1.1GHz
    Connectivity OptionsBluetooth 5.3 class 2, USB-C
    Display TypeNone
    Memory1GB RAM, 8GB Flash
    Power Supply Voltage100 - 240 V at 50 - 60 Hz
    Battery TypeNo Battery
    Mounting Type4 Screws (not included)
    Operating SystemLinux
    ISO Conformance StandardsISO 18000-63 (EPC Class 1Gen2v2)
    Data ManagementNordic ID RADEA
    API SupportNUR API for RFID and RESTful service to access reader configuration
    External Antenna Port4 ports RP-SMA female
    Device Indicators4 LEDs indicating the enabled antennas, Application LED, Connection LED, Extension port LED, Power LED, RF LED
    Ingress Protection RatingIP20
    RoHS Compliance StatusCompliant with Directive 2011/65/EU and 2015/863
    Notes

    * Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

    Product Details
    Dimensions0.69 in H x 8 in W x 3.09 in D
    Reading SpeedUp to 1000 tags per second
    Weight0.353 lb
    ColorSilver, Blue
    ApplicationAsset Tracking, Inventory and Inspection Labeling, RFID labeling, Temperature Indicating Labeling
    Shipped With BatteryNo
    Central Processing Unit (CPU)Quad-core A7 1.1GHz
    Connectivity OptionsBluetooth 5.3 class 2, USB-C
    Display TypeNone
    Memory1GB RAM, 8GB Flash
    Power Supply Voltage100 - 240 V at 50 - 60 Hz
    Battery TypeNo Battery
    Mounting Type4 Screws (not included)
    Operating SystemLinux
    ISO Conformance StandardsISO 18000-63 (EPC Class 1Gen2v2)
    Data ManagementNordic ID RADEA
    API SupportNUR API for RFID and RESTful service to access reader configuration
    External Antenna Port4 ports RP-SMA female
    Device Indicators4 LEDs indicating the enabled antennas, Application LED, Connection LED, Extension port LED, Power LED, RF LED
    Ingress Protection RatingIP20
    RoHS Compliance StatusCompliant with Directive 2011/65/EU and 2015/863
    Note

    Note: Please read description carefully. Do not base your order on the picture presented.
