| Video |
| IP Video Input | 16 Channels |
| Output | - HDMI: 3840 x 2160 at 60fps; 3840 x 2160, 1920 x 1080, 1280 x 1024, 1024 x 768 at 30 fps
- VGA x 1: 1920 x 1080 / 1280 x 1024 / 1024 x 768
|
| IP Video Input Resolution | 12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 1280 x 1024 / 960P / 720P / 960H / D1 / CIF |
| Incoming Bandwidth (Mbps) | 112 |
| Outgoing Bandwidth (Mbps) | 112 |
| Video Compression | Standard H.264 / H.265 |
| Audio |
| Network Input | 16 Channel IPC Audio Input |
| Local Output | RCA x 1 |
| 2-Way Audio | RCA x 1 |
| Recording |
| Resolution | 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P |
| Frame Rate | 30 fps (NTSC) / 25 fps (PAL) |
| Record Stream | Dual Stream Recording |
| Playback |
| Smart Search | - Recorded Events are Color-Coded to Reflect the Specific Type of Event that was Recorded
- (Scheduled, Motion, Alarm, Etc.)
|
| Search | Time slice / Time / Event / Tag Search |
| Simultaneous Playback | Max 16 Channels |
| Alarm |
| Alarm Input | IPC Alarm Input Supported |
| Alarm Output | IPC Alarm Output Supported |
| Mode | Manual, Sensor, Motion, Exception |
| Alarm Trigger | Record, Snap, Preset, E-mail, etc. |
| Storage |
| HDD Interface | SATA x 2, Max 10TB per HDD |
| Backup |
| Network Backup | Yes |
| Local Backup | USB Flash Drive, USB Mobile HDD |
| Network |
| Interface | RJ45 10 / 100 / 1,000 Mbps |
| PoE Port | RJ45 x 16 |
| Protocol | TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, 802.1x |
| External Interface |
| Remote Controller | Optional |
| USB | USB 2.0 x 1 (Front Panel), USB 3.0 x 1 (Rear Panel) |
| Video Analytics |
| License Plate Recognition | Supported on v1.4.4 (used with the AVC-NBL21M-L1 & AVC-NBL41M-L1) |
| General |
| Power Supply | DC 48V |
| Power Consumption | ≤15W (Without HDD) |
| Working Environment | -4°~122°F (-20°~50° Celcius) |
| Working Humidity | 10% ~ 90% (Non-Condensing) |
| Dimensions | 15.00" x 10.50" x 2.00"(381.0mm x 266.7mm x 50.8mm) |
