Avycon, AVR-NN832E2N-FD-32T, 32 Channels 4K UHD Network Video Recorder,32TB

Features:

Supports up to 32 Channels 12MP / 8MP / 5MP / 4MP/ 3MP / 1080P 960P / 720P IP Camera video input
Supports H.265 High Profile Compression with Up to 50% Savings in bandwidth over H.264
Intuitive and User-Friendly Graphic User Interface (GUI)
True 4K HDMI Output
Multi-Mode Recording: Manual / Scheduled / Motion & Sensor
Playback: 16 Channels Simultaneous Playback
Search: Time Slice, Time, Event, Tag, Smart and Target Database Search
Supports Facial Detection and Comparison
Supports Multiple Video Analytics, such as Missing or Abandoned Object, Region Intrusion, Tripwire, Video Tampering, etc.
Supports POS Information Overlay on Live View and Playback
Supports Hardware RAID: RAID0, 1, 5, 6, 10
Quick and Easy Backup via USB, Network and Mobile App
Pentaplex Operation : Live View, Record, Playback, Backup and Remote Access
Supports DHCP, DDNS, PPPoE and various other Network Protocols
Compatibility with a Variety of 3rd-Party IP Cameras including ONVIF, Hikvision, and Others
Remote Access via Web Interface or avycon CVMS : Live View, Playback, Backup, PTZ, and System Configuration
Dual Stream Technology allows for High Quality Local Recordings and Standard Quality Video for Mobile and Remote Access
Allows Simultaneous Online Users to Access Device
Support PTZ Preset and Auto-Cruise, with Up to 255 Presets and 8 Cruise Paths
Support NAT Function and QR Code Scanning by Mobile Apps, Eliminating the Need to Configure Port Forwarding
Powerful Mobile Apps on iOS and Android
NDAA Compliant

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

VIDEO
IP Video Input	32 Channels
Output	HDMI1: 3840 x 2160 at60fps / 3840 x 2160 at30fps / 1920 x 1080 / 1280 x 1024 / 1024 x 768 HDMI2 /HDMI3 / HDMI4 / VGA x 1: 1920 x 1080 / 1280 x 1024 / 1024 x 768
IP Video Input Resolution	12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 1280X1024 / 960P / 720P / 960H / D1 / CIF
Incoming Bandwidth (Mbps)	640
Outgoing Bandwidth (Mbps)	Display Priority: 128, Network Priority: 640
Video Compression	Standard H.264 / H.265
AUDIO
Network Input	32 Channel IPC Audio Input
Local Output	RCA x 1
2-Way Audio	RCA x 1
HDMI Audio Output	Yes
Compression	G.711(U/A)
RECORDING
Resolution	12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 1280x1024 / 960P / 720P / 960H / D1 / CIF
Frame Rate	25fps(PAL) / 30fps(NTSC)
Record Stream	Dual Stream Recording
Mode	Manual, Timer, Motion, Sensor, Smart Events
PLAYBACK
Smart Search	Recorded Events are Color-Coded to Reflect the Specific Type of Event that was Recorded (Scheduled, Motion, Alarm, Etc.)
Search	Time slice / Time / Event / Tag Search
Simultaneous Playback	Max 16 Channels
Live / Playback	Channel at 12MP / 4 Channels at 5MP / 9 Channels at 720P / 16 Channels at 720P
ALARM
Alarm Input	24 Channels Local Alarm Input; IPC Alarm Input Supported
Alarm Output	8 Channels
Mode	Manual, Sensor, Motion, Exception, Smart Events
FACE
Face Detection (Camera Detection)	32 Channels
Face Detection (NVR Detection)	4 Channels
Face Match Performance	16 Channels
Face Picture Database	32 Libraries; 5,000 Face Pictures
Comparison Capability	36 Pictures/second
Face Picture Adding	Ability to Add Face Pictures via Mobile App, Web Interface, and NVR Local GUI
Face Picture Search	Yes
Face Tracking	Yes
Database Management	Add, Modify, Delete, and Search Face Pictures
Face Picture Comparison	Supports Standard Comparison, with the Ability to Add Faces to an Allowed or Block List
Face Track Map	Resolution: ≤2560 x 1920; Size: ≤512KB; Formats: .jpg, .jpeg
External Face Picture Enrollment	Resolution: 128 x 128 ~ 1920 x 1080; Size: ≤70KB; Formats: .jpg, jpeg
Face Info Statistic Mode	Statistics by Day, Week, Month, Quarter as well as Customized Time Period
Face Info Statistic Graph	Bar Graph
STORAGE
HDD Interface	SATA x 8, Max 18T per HDD; e-SATA x 1
RAID Type	RAID0, 1, 5, 6, 10
BACKUP
Network Backup	Yes
Local Backup	USB Flash Drive, USB Mobile HDD
NETWORK
Interface	RJ45 10 / 100 / 1,000 Mbps x 2
Protocol	TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, 802.1x
EXTERNAL INTERFACE
RS-485	Yes (Full-Duplex), Connect to PTZ keyboard
RS-232	Yes
Reset	Yes
USB	USB 2.0 x 2, USB 3.0 x 1
GENERAL
Power Supply	ATX 250W
Power Consumption	≤50W (Without HDD)
Working Environment	5°~122°F (-15°~50° Celcius)

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

VIDEO
IP Video Input	32 Channels
Output	HDMI1: 3840 x 2160 at60fps / 3840 x 2160 at30fps / 1920 x 1080 / 1280 x 1024 / 1024 x 768 HDMI2 /HDMI3 / HDMI4 / VGA x 1: 1920 x 1080 / 1280 x 1024 / 1024 x 768
IP Video Input Resolution	12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 1280X1024 / 960P / 720P / 960H / D1 / CIF
Incoming Bandwidth (Mbps)	640
Outgoing Bandwidth (Mbps)	Display Priority: 128, Network Priority: 640
Video Compression	Standard H.264 / H.265
AUDIO
Network Input	32 Channel IPC Audio Input
Local Output	RCA x 1
2-Way Audio	RCA x 1
HDMI Audio Output	Yes
Compression	G.711(U/A)
RECORDING
Resolution	12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 1280x1024 / 960P / 720P / 960H / D1 / CIF
Frame Rate	25fps(PAL) / 30fps(NTSC)
Record Stream	Dual Stream Recording
Mode	Manual, Timer, Motion, Sensor, Smart Events
PLAYBACK
Smart Search	Recorded Events are Color-Coded to Reflect the Specific Type of Event that was Recorded (Scheduled, Motion, Alarm, Etc.)
Search	Time slice / Time / Event / Tag Search
Simultaneous Playback	Max 16 Channels
Live / Playback	Channel at 12MP / 4 Channels at 5MP / 9 Channels at 720P / 16 Channels at 720P
ALARM
Alarm Input	24 Channels Local Alarm Input; IPC Alarm Input Supported
Alarm Output	8 Channels
Mode	Manual, Sensor, Motion, Exception, Smart Events
FACE
Face Detection (Camera Detection)	32 Channels
Face Detection (NVR Detection)	4 Channels
Face Match Performance	16 Channels
Face Picture Database	32 Libraries; 5,000 Face Pictures
Comparison Capability	36 Pictures/second
Face Picture Adding	Ability to Add Face Pictures via Mobile App, Web Interface, and NVR Local GUI
Face Picture Search	Yes
Face Tracking	Yes
Database Management	Add, Modify, Delete, and Search Face Pictures
Face Picture Comparison	Supports Standard Comparison, with the Ability to Add Faces to an Allowed or Block List
Face Track Map	Resolution: ≤2560 x 1920; Size: ≤512KB; Formats: .jpg, .jpeg
External Face Picture Enrollment	Resolution: 128 x 128 ~ 1920 x 1080; Size: ≤70KB; Formats: .jpg, jpeg
Face Info Statistic Mode	Statistics by Day, Week, Month, Quarter as well as Customized Time Period
Face Info Statistic Graph	Bar Graph
STORAGE
HDD Interface	SATA x 8, Max 18T per HDD; e-SATA x 1
RAID Type	RAID0, 1, 5, 6, 10
BACKUP
Network Backup	Yes
Local Backup	USB Flash Drive, USB Mobile HDD
NETWORK
Interface	RJ45 10 / 100 / 1,000 Mbps x 2
Protocol	TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, 802.1x
EXTERNAL INTERFACE
RS-485	Yes (Full-Duplex), Connect to PTZ keyboard
RS-232	Yes
Reset	Yes
USB	USB 2.0 x 2, USB 3.0 x 1
GENERAL
Power Supply	ATX 250W
Power Consumption	≤50W (Without HDD)
Working Environment	5°~122°F (-15°~50° Celcius)

Note

Note: Please read description carefully. Do not base your order on the picture presented.
