| Camera |
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Image Size | 2592x1944 |
| Shutter Speed | 1/5s to 1/20000s |
| Min. Illumination | Color: 0.003 Lux at (F1.6, AGC ON), B/W:0 Lux with IR |
| IR Distance | Up to 150m |
| Lens | 4.3mm to 142mm at F No. 1.6 H: 55(W) - 2.3(T)° V: 41.6(W) - 1.7(T)° D：67.9(W) - 2.8(T)° |
| Lens Mount | Motorized(Ø14) |
| Day & Night | IR cut filter with auto switch (Day/Night/Auto/Image/Schedule) |
| Wide Dynamic Range | 120dB |
| Digital NR | 3D DNR |
| Backlight Compensation (BLC) | Off/On (5 Zone) |
| Highlight Compensation (HLC) | Yes |
| Defog | Yes |
| Gain Control | Auto |
| White Balance | Auto/Manual |
| Flip/Mirror | Yes |
| PTZ |
| Pan Range | 360° |
| Pan Speed | Configurable from 0.6° to 200°/s; preset speed: 200°/s |
| Tilt Range | -10° to 90° (auto flip) |
| Tilt Speed | Configurable from 0.6° to 90°/s, preset speed 100°/s |
| Optical Zoom | 33x |
| Proportional Zoom | Yes |
| Preset | 255 |
| Patrol Scan | 1 |
| Patrol Scan | 4 |
| Power-Off Memory | Yes |
| 3D Positioning | Yes |
| Auto Tracking | Yes |
| Viedo Image |
| Video Compression | H.265+/H.265/H.264+/H.264/MJPEG |
| Resolution | 5MP(2592x1944) 4MP(2592x1520), 3MP(2048x1536 / 2304x1296), 1080P(1920x1080), 20P(1280x720), VGA(640x480),QVGA(320x240) at50/60 Hz |
| Main Stream | - 60Hz: 5MP(2592x1944) at 20FPS / 4MP(2560x1440), 3MP(2048x1536 / 2304x1296), 1080P(1920x1080), 720P(1280x720) at 30 FPS 50Hz:
- 5MP(2592x1944) at 20FPS / 4MP(2560x1440), 3MP(2048x1536 / 2304x1296), 1080P(1920x1080), 720P(1280x720) at 25 FPS
|
| Sub Stream | 60Hz: 720P(1280x720), VGA(640x480), QVGA(320x240) at30FPS, 50Hz: 720P(1280x720), VGA(640x480), QVGA(320x240) at 25FPS |
| Third Stream | 60Hz: QVGA（340x480, 320x240） at 30FPS, 50Hz: QVGA（340x480,320x240） at 25FPS |
| Video Bit Rate | 256Kbps ~ 8Mbps |
| Image Settings | Day & Night, BLC, WDR, DNR, Privacy Masking, WhiteBalance |
| ROI | N/A |
| Network / Interface |
| Network | RJ45(10/100BASE-T) |
| Network Protocol | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,SMTP,NTP,UPnP,SNMP,HTTPS,FTP |
| Interface Protocol | ONVIF( Profile S/G/T) |
| Web Browser | Mircosoft Edge, Safari, Firefox, Google Chrome |
| Online Connection | Support simultaneous monitoring for up to 3 users; Support multi-stream real time transmission |
| Security | IP Address Filter; Complicated Password; Authenticated Username and Password |
| Streaming Method | Unicast / Multicast |
| Storage | Built-in micro SD card slot, up to 1TB |
| Video Output | 1 inputs, 1 output |
| Audio | 1 inputs, 1 output |
| Alarm | N/A |
| Hardware Reset | N/A |
| Dori Distance |
| Lens | - 4.3 ~ 142 mm (T)
- 4.3 ~ 142 mm (W)
|
| Observe | - 140.7ft (42.9m)
- 3362.5ft (1024.9m)
|
| Detect | - 354.3ft (108m)
- 8373.7ft (2582.8m)
|
| Recognize | - 70.9ft (21.6m)
- 1694.8ft (516.6m)
|
| Identify | - 35.4ft (10.8m)
- 847.4ft (258.3m)
|
| FunctionS |
| Remote Monitoring | Avycon CMSONE, Avycon Moblie One |
| Smart Alarm | Motion detection |
| Smart Analytics | - Face Recognition (FR) Human&Vehicle Detection (PD&VD) Perimeter Intrusion Detection (PID) Line Crossing Detection (LCD)
- Cross Counting (CC) Stationary Object Detection (SOD) Heat Map (HM) Crowd Density Detection (CD) Queue Lenght Detection (QD)
- license Plate Detection (LPD) Rare Sound Detection (RSD)
|
| General |
| Power Supply | DC 12V/POE+, max. 25.6W |
| Power Consumption | N/A |
| Operating Environment | -22 °F to 149 °F (-30 °C to 60 °C) Humidity 90% or less (non-condensing) |
| Dimensions (in) | 8.12 x 16.25in (206.50 X 413.00mm) |
| Weight (lb) | 8.15lb |
| Ingress Protection | IP66 |
