Options and Related Products

Type:: Type: HDMI Live Streaming Switcher

HVS0402U Includes Only:

Micro 4 Channel HDMI Live Streaming Video Switcher
12V Power Supply
USB-A to USB-C Cable
Tally Connector

Features:

4 channel auto-detected HDMI inputs
1xHDMI PGM output,1xHDMI multiview out, 1xUSB type-C output
AUX output configurable and assignable
USB-C for capturing and streaming on PC
Clearly visible multiview & status page
Upstream key: Luma key, Chroma key, PIPx2/ POP
Downstream key and LOGO overlay
T-bar/ Auto/ Cut transitions; various effects: WIPE(9x2 patterns) / MIX/ DIP
Audio mixer: HDMI embedded audio and 2-Ch MIC/ line In; audio delay available
Media library: 49 default patterns, 16 imported images, 16 captured images, 2 color generators
LAN port for PC software remote control
FTB/ MUTE/ STILL/ GPIO for tally customer configuration import and export

Live Stream Video

Abundant Applications

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Processing

Switching Type

Pushbutton, Software, T-Bar

Processing Resolution

1080p

Color Processing

Input

Number of Video Input Sources

Video Inputs

4x HDMI Female

Input Video Format (HDMI)

1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080i at 50/59.94/60 fps
720p at 23.98/24/25/29.97/30/50/59.94/60 fps
576p at 50 fps
576i / 625 lines at 50 fps
480p at 59.94/60 fps
480i / 525 lines at 59.94/60 fps

Audio Inputs

2x 1/8" / 3.5 mm TRS Stereo Analog Female

Input Audio Format

Analog

Embedded Audio Input

HDMI: 2-Channel (per Input)

Output

Video Output Channels

Video Outputs

1x HDMI Female (Program)
1x HDMI Female (Monitor)
1x USB-C (USB Video) Female

Output Video Format

HDMI
- 1080p at 24/25/30/50/60 fps
- 1080i at 50/60 fps
USB-C
- 1080p at 60 fps

Audio Outputs

1x 1/8" / 3.5 mm TRS Stereo Analog Female (Loop Output)

Output Audio Format

Analog

Embedded Audio Output

HDMI: 2-Channel (per Output)
USB-C: 2-Channel (per Output)

Multiview Output

4-Way Multiview via HDMI

Monitor Output

1x HDMI

General

Dimensions

9.63 x 5.64 x 1.75" / 24.45 x 14.32 x 4.45cm

Weight

2.3lb / 1kg

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Processing

Switching Type

Pushbutton, Software, T-Bar

Processing Resolution

1080p

Color Processing

Input

Number of Video Input Sources

Video Inputs

4x HDMI Female

Input Video Format (HDMI)

1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
1080i at 50/59.94/60 fps
720p at 23.98/24/25/29.97/30/50/59.94/60 fps
576p at 50 fps
576i / 625 lines at 50 fps
480p at 59.94/60 fps
480i / 525 lines at 59.94/60 fps

Audio Inputs

2x 1/8" / 3.5 mm TRS Stereo Analog Female

Input Audio Format

Analog

Embedded Audio Input

HDMI: 2-Channel (per Input)

Output

Video Output Channels

Video Outputs

1x HDMI Female (Program)
1x HDMI Female (Monitor)
1x USB-C (USB Video) Female

Output Video Format

HDMI
- 1080p at 24/25/30/50/60 fps
- 1080i at 50/60 fps
USB-C
- 1080p at 60 fps

Audio Outputs

1x 1/8" / 3.5 mm TRS Stereo Analog Female (Loop Output)

Output Audio Format

Analog

Embedded Audio Output

HDMI: 2-Channel (per Output)
USB-C: 2-Channel (per Output)

Multiview Output

4-Way Multiview via HDMI

Monitor Output

1x HDMI

General

Dimensions

9.63 x 5.64 x 1.75" / 24.45 x 14.32 x 4.45cm

Weight

2.3lb / 1kg

Note

Note: Please read description carefully. Do not base your order on the picture presented.
