AViPAS AV-3104SE 4D Serial Joystick Controller w/o IP Function

AV-3104SE Includes Only:

• 3-axis control keyboard
• 5pin plug (on the unit)
• DC-12V power adapter
• 8ft RS232 cable (9-Pin DB-9 Female to 8-Pin Mini-DIN Male)
• User manual

Features:

• Simultaneous pan/tilt/zoom control, adjustable speed
• The button on the joystick provides a lock/unlock function
• Communication: RS485 half-duplex, RS422 full duplex, RS232 serial
• Support VISCA, Pelco-P, and Pelco-D protocols
• Baud rate: 1200/2400/4800/9600 bps
• LED status and menu display

AV-3104SE is a 4D joystick PTZ camera keyboard controller with an LCD Display. The communication port between the keyboard and the receiving terminal (camera) is RS232/RS422 (RS-485). The keyboard can control up to 255 PTZ cameras within a maximal communication range of 1.2 KM.
