Buy Audio Technica ATW-R1440, System 20 PRO 4-Channel Receiver

info@megasolutions.llc

1-855-969-9322
1-908-282-3332 (Intl.)

Features:

Half-rack chassis capable of receiving up to four transmitters
Each receiver channel can be paired with up to four transmitters, allowing users to instantly switch between different transmitter configurations
Switch between Standard (10 channels) and HD (20 channels) modes
Receiver units can be docked in the chassis or mounted remotely (up to 328 feet away) via Ethernet cable for added versatility
Up to five chassis can be linked and used simultaneously
Monitor transmitter status, audio level, remaining battery time, and other information in A-T Wireless Manager
Auto-lock function prevents unintended operations

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Operating Frequencies	2,402 to 2,480 MHz
Dynamic Range	120 dB (A-weighted), typical
Total Harmonic Distortion	< 0.05%, typical
Maximum Simultaneous Use (recommended)	Standard: 10 channels HD mode: 20 channels It depends on the region and environment.
System Frequency Response	20 to 20,000 Hz Varies depending on the microphone to be installed.
Delay	Standard: 2.8ms HD mode: 6.7ms
Audio Sampling Rate	Standard: 24-bit/48 kHz HD mode: 24-bit/48 kHz
Encryption Method	AES128

Operating Frequencies	2,402 to 2,480 MHz
Dynamic Range	120 dB (A-weighted), typical
Total Harmonic Distortion	< 0.05%, typical
Maximum Simultaneous Use (recommended)	Standard: 10 channels HD mode: 20 channels It depends on the region and environment.
System Frequency Response	20 to 20,000 Hz Varies depending on the microphone to be installed.
Delay	Standard: 2.8ms HD mode: 6.7ms
Audio Sampling Rate	Standard: 24-bit/48 kHz HD mode: 24-bit/48 kHz
Encryption Method	AES128

Note: Please read description carefully. Do not base your order on the picture presented.
