Options and Related Products

CPU:: CPU: 2U AMD EPYC7000

Features:

2U Rackmount with 1+1 2000W Redundant PSU
Single Socket SP3 (LGA 4094), supports AMD EPYC™ 7003 (with AMD 3D V-Cache™ Technology * )/7002 series processors
8 DIMM slots (1DPC), supports DDR4 RDIMM, LRDIMM, RDIMM/LRDIMM-3DS
4 dual-slot PCIe4.0 x16, 1 PCIe4.0 x16
3 x 2.5" SATA drive bays, 1 x 2.5" NVMe/SATA drive bay, 1 x 2.5" NVMe drive bay
2 RJ45 (10GbE) by Intel ^® X550-AT2
1 OCP 2.0 connector A and B (2 PCIe3.0 x8)
Remote Management (IPMI)

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Chassis height

2U Rackmount

Chassis model

2U4G-ROME

Dimensions (DxWxH)

438x 795x 87.5 mm(without ear)

Motherboard size

ATX, 12'' x 9.6'' ( ROMED8QM-2T )

I/O port

2 x USB 2.0 ports

Front hot-swappable hard drive tray

4 x2.5" SATA 6GB/s HDDs(1x SATA3 HDD could support NVME or SATA3 6GB/s HDDs) + 1x NVME

Specification

2 (1+1), Redundant

Output Power

2000W, Platinum

AC input

High Line 200-240V, 50/60Hz

Fan

80 x 38 mm x 6

GPGPU Watts

-Max 350w/per card

Support GPGPU

4 x PCIe4.0 x16 GPGPU/MIC card (Double width)

Size

12''x9.6''

CPU

Supports AMD EPYC™ 7003 (with AMD 3D V-Cache™ Technology * )/7002 Series Processors

capacity

8 DIMM slots

Specification

8 Channels memory technology

DIMM Size Per DIMM

RDIMM: 64GB, 32GB, 16GB

Max. DIMM Frequency

RDIMM: 3200/2933MHz

Voltage

1.2V

PCIe x 16

1 PCIe4.0 x16 (in the rear side)

Mezzanine tank

1 x OCP Mezzanine Type A (Gen3 x8 )

M.2

1 M-key (PCIe3.0 x4 or SATA 6Gb/s), supports 2280/2242 form factor

Interface

10000/1000/100/10 Mbps by Intel ® X550

Additional GbE Controller

2 x RJ45 10G base-T by Intel ® X550
1 x RJ45 Dedicated IPMI LAN port by RTL8211E

Integrated Baseboard Management Controller

ASPEED AST2500

Intelligent platform out-of-band management interface

1 x Realtek RTL8211E for dedicated management GLAN

Controller

ASPEED AST2500

video random access memory

DDR4 256Mb

Display connector

1 DB15 (VGA)

USB 3.2 Gen1 port

2 Type-A (USB3.2 Gen1)

RJ-45 network port

2 RJ45 (10GbE)

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Chassis height

2U Rackmount

Chassis model

2U4G-ROME

Dimensions (DxWxH)

438x 795x 87.5 mm(without ear)

Motherboard size

ATX, 12'' x 9.6'' ( ROMED8QM-2T )

I/O port

2 x USB 2.0 ports

Front hot-swappable hard drive tray

4 x2.5" SATA 6GB/s HDDs(1x SATA3 HDD could support NVME or SATA3 6GB/s HDDs) + 1x NVME

Specification

2 (1+1), Redundant

Output Power

2000W, Platinum

AC input

High Line 200-240V, 50/60Hz

Fan

80 x 38 mm x 6

GPGPU Watts

-Max 350w/per card

Support GPGPU

4 x PCIe4.0 x16 GPGPU/MIC card (Double width)

Size

12''x9.6''

CPU

Supports AMD EPYC™ 7003 (with AMD 3D V-Cache™ Technology * )/7002 Series Processors

capacity

8 DIMM slots

Specification

8 Channels memory technology

DIMM Size Per DIMM

RDIMM: 64GB, 32GB, 16GB

Max. DIMM Frequency

RDIMM: 3200/2933MHz

Voltage

1.2V

PCIe x 16

1 PCIe4.0 x16 (in the rear side)

Mezzanine tank

1 x OCP Mezzanine Type A (Gen3 x8 )

M.2

1 M-key (PCIe3.0 x4 or SATA 6Gb/s), supports 2280/2242 form factor

Interface

10000/1000/100/10 Mbps by Intel ® X550

Additional GbE Controller

2 x RJ45 10G base-T by Intel ® X550
1 x RJ45 Dedicated IPMI LAN port by RTL8211E

Integrated Baseboard Management Controller

ASPEED AST2500

Intelligent platform out-of-band management interface

1 x Realtek RTL8211E for dedicated management GLAN

Controller

ASPEED AST2500

video random access memory

DDR4 256Mb

Display connector

1 DB15 (VGA)

USB 3.2 Gen1 port

2 Type-A (USB3.2 Gen1)

RJ-45 network port

2 RJ45 (10GbE)

Note

Note: Please read description carefully. Do not base your order on the picture presented.
