Apantac KVM-IP-Tx-UHD-L MT Hood KVM Extender 4K UHD 60 Hz RJ45 (GigE)

Apantac, KVM-IP-Tx-UHD-L, MT Hood KVM Extender, 4K UHD 60 Hz, Gigabit Ethernet

Features:

• Based on Gigabit Ethernet Technology (IGMP and Jumbo frame)
• Supports HDR 10/10+, HDCP 2.2/2.3
• Supports USB 2.0 over IP
• Supports AES 265 encryption
• Low latency of 17 ms for 60Hz, 20 ms for 50Hz
• Transmitter has built-in HDMI looping input
• Supports up to 170 meters point to point extension with CAT6 cable
• Supports up to 100 meters when used with a GigE switch
• Supports HDMI inputs and output signals
• Supports point to point (Unicast), point to multi-point (Multicast) for Audio/Video distribution
• Receiver has 3 USB ports that supports both HID and transparent USB (for USB storage, and tablets)
• Supports analog stereo audio in point to point mode. Both embedded HDMI as well as external stereo input
• Supports RS-232 communication between Tx and Rx
• Built-in web-page for configuration
• Connection manager software - KVM matrix control panel
• Supports resolutions up to UHD at 60Hz
• Advanced EDID management functionality. Built-in EDID list or EDID from the display
• Built-in Scaler on the receivers
• POE Optional - Hardware option can be included at the time of order

Front View

• RS-232
• Infrared In/Out
• 1 x USB Type B (Keyboard/Mouse)
• 1 x Analog Audio input
• Link Start/Stop button
• Button Reserved
• 1 x USB Type B (Transparent)
• Status LEDs

Rear View

• Ethernet
• SPDIF output
• HDMI Input
• HDMI Loop out
• 1 x 12V DC

For more information, please see Data Sheet
