Features:

IEEE 802.3af (15W) and IEEE 802.3at (30W) compliant.
Sixteen (16) ports for cameras/edge devices over ethernet.
Speed: 10/100/1000 Mbps.
30W maximum power per port.
Port status LEDs.
Auto detection and protection of legacy non-PoE cameras/devices.
Real-time power diagnostics with e-mail and
Windows Dashboard Alert notifications.
Local and/or remote access to critical information via LAN/WAN.
Event Log tracks history.
Built-in IP networked management allows for remote camera reset and monitoring.
Built-in battery charger.
UL Listed in the U.S. and Canada.
CE Approved.

Altronix NetWay16G is a 16-port networked Managed Midspan in a 1U rack enclosure. It provides PoE/PoE+ (up to 30W power per port), and passes data at 10/100/1000 Mbps at distances up to 100m. Features also include an integral battery charger for applications requiring backup and embedded LINQ™ Technology to monitor, control, and report power and diagnostics from anywhere.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Subject to the use of all the optional accessories
Input Voltage	115VAC, 60Hz, 4.5A or 230VAC, 50/60Hz, 3A.
Power	Unit supplies PoE output voltage (55V) and up to 30W max. full power per port. Total power: NetWay16G - 480W IEEE 802.3af and IEEE 802.3at compliant (PoE/PoE+). Short circuit protection.
Ethernet	Sixteen (16) ports for cameras/edge devices over ethernet. Wire type: 4-pair CAT5e and higher. Speed: 10/100/1000 Mbps.
Functions	Auto detection and protection of legacy non-PoE cameras/edge devices.
Visual Indicators	Yellow and Green LED (by RJ45 jack): IP Link status, 10/100/1000 Base-T/active. Green LED: Port status.
Battery Backup	Built-in battery charger (optional rack mount battery enclosure - RE2). Automatic switchover to stand-by battery when AC fails.
LINQ Technology	SSL (Secure Socket Layer) security encryption. User level security. Built-in IP management allows for remote camera reset and monitoring. Provides local and/or remote access to critical information via LAN/WAN Email and Windows Dashboard Alert notifications report real-time diagnostics. Event log tracks history.
Temperature	Operating: - 20° C to 40° C ( - 4° F to 104° F). Storage: - 20° to 70° C ( - 4° F to 158° F). Relative Humidity 85% +/- 5%. BTU/Hr. (approx.): 245 BTU/Hr.
Operating Altitude	Up to 2,000m.
Enclosure Dimensions (H x W x D approx.)	1.625" x 19.125" x 8.5" (41.3mm x 486mm x 216mm).
Agency Listings	UL/cUL UL60950-1 (Information Technology Equipment). CE European Conformity.

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Subject to the use of all the optional accessories
Input Voltage	115VAC, 60Hz, 4.5A or 230VAC, 50/60Hz, 3A.
Power	Unit supplies PoE output voltage (55V) and up to 30W max. full power per port. Total power: NetWay16G - 480W IEEE 802.3af and IEEE 802.3at compliant (PoE/PoE+). Short circuit protection.
Ethernet	Sixteen (16) ports for cameras/edge devices over ethernet. Wire type: 4-pair CAT5e and higher. Speed: 10/100/1000 Mbps.
Functions	Auto detection and protection of legacy non-PoE cameras/edge devices.
Visual Indicators	Yellow and Green LED (by RJ45 jack): IP Link status, 10/100/1000 Base-T/active. Green LED: Port status.
Battery Backup	Built-in battery charger (optional rack mount battery enclosure - RE2). Automatic switchover to stand-by battery when AC fails.
LINQ Technology	SSL (Secure Socket Layer) security encryption. User level security. Built-in IP management allows for remote camera reset and monitoring. Provides local and/or remote access to critical information via LAN/WAN Email and Windows Dashboard Alert notifications report real-time diagnostics. Event log tracks history.
Temperature	Operating: - 20° C to 40° C ( - 4° F to 104° F). Storage: - 20° to 70° C ( - 4° F to 158° F). Relative Humidity 85% +/- 5%. BTU/Hr. (approx.): 245 BTU/Hr.
Operating Altitude	Up to 2,000m.
Enclosure Dimensions (H x W x D approx.)	1.625" x 19.125" x 8.5" (41.3mm x 486mm x 216mm).
Agency Listings	UL/cUL UL60950-1 (Information Technology Equipment). CE European Conformity.
