AIDA Imaging, HD-X3L-IP67, Optical Zoom POV Camera, FHD Weatherproof 3G-SDI 3.5X

HD-X3L-IP67 Includes Only:

Camera
DC 12v Power Supply & Sockets Adapter

Introducing the camera where no other AIDA products have gone before; the outdoors. Indulge in almost any environment with IP67 rated protection, covering against dust, moisture, and even water submersion up to 1m for 30 minutes. These are ideal characteristics for all-weather sporting events, professional biology research, and OB vehicles looking for that next scoop.

NDI® is a registered trademark of NewTek, Inc.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Image Sensor

1/3" Progressive CMOS

Sensor Size

Diagonal 7.20mm

Effective Pixels

Horizontal: 1920, Vertical: 1080

Pixel Size

2.75 μm (H) x 2.75 μm (V)

Resolution

1080p / 1080i: 1920 x 1080
720p: 1280 x 720

Resolution Rate

1080p: 60 / 59.94 / 50 / 30 / 29.97 / 25 / 24
1080i: 60 / 59.94 / 50i 720
720p: 60 / 59.94 / 50p

Output

3G-SDI

Color Space

4:2:2 (YCbCr) 10bit

White Balance

AWB / AE / AF

Exposure

Full Auto, Bright, Shutter Priority, Iris Priority, Manual

Other

WDR, DIS (Digital Image Stabilization), 2D/3D Noise Reduction, Digital Slow Shutter, Black Level Compensation, Flicker Detection

Lens

3X Optical Zoom Lens, 3.85mm/78° (Wide) ~ 13.4mm/25° (Tele)

SMPTE

SMPTE 292M, SMPTE 424M

Weatherproof Rating

IP67

Camera Control

RS-485 OSD Button

Operation Temp

32°F – 104°F

Dimension

48mm x 48mm x 83.09mm / 1.89" x 1.89" x 3.27"

Weight

140g / 0.30lbs

Power

12 VDC (+9 – +15VDC)

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Image Sensor

1/3" Progressive CMOS

Sensor Size

Diagonal 7.20mm

Effective Pixels

Horizontal: 1920, Vertical: 1080

Pixel Size

2.75 μm (H) x 2.75 μm (V)

Resolution

1080p / 1080i: 1920 x 1080
720p: 1280 x 720

Resolution Rate

1080p: 60 / 59.94 / 50 / 30 / 29.97 / 25 / 24
1080i: 60 / 59.94 / 50i 720
720p: 60 / 59.94 / 50p

Output

3G-SDI

Color Space

4:2:2 (YCbCr) 10bit

White Balance

AWB / AE / AF

Exposure

Full Auto, Bright, Shutter Priority, Iris Priority, Manual

Other

WDR, DIS (Digital Image Stabilization), 2D/3D Noise Reduction, Digital Slow Shutter, Black Level Compensation, Flicker Detection

Lens

3X Optical Zoom Lens, 3.85mm/78° (Wide) ~ 13.4mm/25° (Tele)

SMPTE

SMPTE 292M, SMPTE 424M

Weatherproof Rating

IP67

Camera Control

RS-485 OSD Button

Operation Temp

32°F – 104°F

Dimension

48mm x 48mm x 83.09mm / 1.89" x 1.89" x 3.27"

Weight

140g / 0.30lbs

Power

12 VDC (+9 – +15VDC)

Note

Note: Please read description carefully. Do not base your order on the picture presented.
