| Camera |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Image Size | 3840x2160 |
| Shutter Speed | 1/3s to 1/100,000s |
| Min. Illumination | Color: 0.02 lux at F1.6(AGC ON); BW: 0 lux with IR |
| IR Distance | Up to 98ft |
| Lens | Fixed 2.8 mm at F1.6 Horizontal FoV: 104° Vertical FoV: 55° Diagonal FoV: 125° |
| Focus | Fixed |
| Lens Mount | M12 |
| Day & Night | ICR |
| Wide Dynamic Range | 120dB |
| Digital NR | 3D DNR |
| Backlight Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | Yes |
| Defog | Yes |
| S/N Ratio | ≥50dB |
| Angle Adjustment | Pan: 0°~360° ; Tilt: 0°~75° ; Rotation:0°~360 |
| Video Image |
| Video Compression | Main stream: H.265+ / H.265 / H.264+ / H.264 Sub/tdird stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| H.264 Compression Standard | Baseline Profile/Main Profile/High Profile |
| Resolution | 8MP (3840x2160), 6MP (3072x2048), 5MP (2592x1944), 4MP (2592x1520), 2K (2560x1440), 3MP (2304x1296), 1080P (1920x1080), 720P (1280x720), D1, CIF, 480 x 240, VGA (640x480) |
| Main Stream | 60Hz: 8MP/6MP/5MP/4MP/2K/3MP/1080P/720P (1~30fps); 50Hz: 8MP/6MP/5MP/4MP/2K/3MP/1080P/720P (1~25fps); HFR mode: 1080P/720P (60Hz: 1~60fps; 50Hz: 1~50fps) |
| Sub Stream | 60Hz: 720P/D1/CIF/VGA/480x240 (1~30fps); 50Hz: 720P/D1/CIF/VGA/480x240 (1~25fps) |
| Third Stream | 60Hz: 720P/D1/480x240/CIF (1~30fps); 50Hz: 720P/D1/480x240/CIF (1~25fps) |
| Video Bit Rate | 64 Kbps ~ 12 Mbps (CBR / VBR Adjustable) |
| Image Settings | ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Mirror, Image Flip, NR, etc. adjustable through client software or web browser |
| ROI | Each ROI to be configured separately |
| Network / Interface |
| Network | 1 x RJ45 10M / 100M Self-Adaptive Ethernet port |
| Network Protocol | UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTMP, RTCP, PPPoE, DDNS, SMTP, FTP, SNMP, HTTP, HTTP POST, 802.1x, UPnP, HTTPS, QoS |
| Interface Protocol | ONVIF (Profile S, G, T, M) |
| Web Browser | IE11 (Plug-in required) / Google Chrome 89.0+ / Edge 89.0+ / Firefox 87.0+ / Safari 14.0+ |
| Online Connection | Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission |
| Security | Video encryption, firmware encryption, HTTPS encryption, configuration encryption, illegal login lock, IP address filtering, 802.1x authentication, basic and digest authentication for HTTP/RTSP |
| Storage | Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission |
| Online Connection | Micro SD/SDHC/SDXC Slot (up to 256GB) with Video and still Image capture Function |
| Video Output | No |
| Audio | 1CH Audio input; 1CH build-in MIC |
| Audio Compression | G711A / U |
| Alarm | No |
| Hardware Reset | Yes |
| Dori Distance |
| Lens | 2.8mm |
| Detect | 272ft (83m) |
| Observe | 108ft (33m) |
| Recognize | 56ft (17m) |
| Identify | 26ft (8m) |
| Functions |
| Remote Monitoring | Web Browser Interface, Mobile App, AVYCON CVMS 2.0 |
| Smart Alarm | Motion detection, SD card error, SD card full, IP address conflict, cable disconnection |
| Smart Analytics | Line crossing, region intrusion/entrance/exiting detection, loitering detection, illegal parking detection, abandoned/missing object detection, Target counting by line/intrusion area/heat map, exception detection, face detection and face capture |
| Video Metadata | Simultaneously captures human body, motor vehicle and non-motor vehicle and extracts 13 human features, 5 motor vehicle features and 1 non-motor vehicle feature |
| General Function | Watermark, Video mask, heartbeat, Image distortion correction, corridor pattern |
| General |
| Power Supply | DC12V / PoE (IEEE802.3af) |
| Power Consumption | <9W |
| Operating Environment | -22°F ~ 140°F (-30°C ~ 60°C) Humidity: less than 95% (non-condensing) |
| Storage Environment | -22°F ~ 149°F (-30°C ~ 65°C) Humidity: less than 95% (non-condensing) |
| Dimensions (in) | Ø 3.72 x 3.25 |
| Weight (lb) | Approx. 1.01 lbs |
| Ingress Protection | IP 67 |
| Certificate | CE, FCC |
| Installation | Ceiling mounting; Wall mounting |
| Environmental Protection | Complies with Directive EU RoHS, WEEE(2012/19/EU), directive 94/62/EC and REACH (EC1907/2006) |
